Commissioning

Commis-
sioning
Stirring
Heating
Contact-
thermometer
connection
GlobalScientificSupply
www.
MS 4 MS 7 MS 10
Put device switch (A) in the ON position
Any set values are retained when device is switched off and even after the device is
disconnected from the power!
Set the engine speed with the operating button (E) on the right
.com
HS 4 HS 7
Put device switch (A) in the OFF position
Plug in (G) mains cable
Once connected to the power supply the device is in "stand-by" mode
The right decimal point on the display (C) is lit
Put device switch (A) in the ON position
Any set values are retained when device is switched off and even after the device is disconnected from the power!
Set the target temperature for the heating plate using operating button (D) [for VHP (E)]
The set value is indicated on the display (C). If energy is being supplied to the heating plate,
In the stir and stand-by modes, "hot" flashes on the display after the heat has been switched off
for as long as the temperature of the set-up surface exceeds 50°C
Put device switch (A) in the OFF position, unplug contact plug
Safety contact thermometer acc. to DIN 12878 class 2 connected with jack (H)
Beware the instruction manual of the contact thermometer
Important: Display (C) also indicates the target temperature of the heating plate when the cont-
GLOBAL SCIENTIFIC SUPPLY
The Laboratory Supply Company!
HS 10 HP 4 HP 7
the red LED (B) lights up
Put device switch (A) in the ON position
act thermometer is connected
info@GlobalScientificSupply.com
HP 10
