Troubleshooting

Before contacting technical support, refer to this section.

On-screen messages

If there is something wrong with the input signal, one of the
following messages appears on the screen. To solve the problem,
see "Trouble symptoms and remedies" on page 35.
If "Out of Range" appears on the screen
This indicates that the input signal is not supported by the
display's specifications. Check the following items.
For more information about on-screen messages, see "Trouble
symptoms and remedies" on page 35.
If "xxx.x kHz / xxx Hz" is displayed
This indicates that either the horizontal or vertical frequency
is not supported by the display's specifications.
The figures indicate the horizontal and vertical frequencies of
the current input signal.
I N FORMA T I ON
Ou t o f R a n g e
XXX . XKH z
If "Resolution i1280 × 768" is displayed
(MFM-HT75W)
This indicates that the resolution is not supported by the
display's specifications (1280 × 768 or less).
I N FORMA T I ON
Ou t o f R a n g e
R e s o l u t i o n > 1
If "Resolution i 1280 × 1024" is displayed
(MFM-HT95)
This indicates that the resolution is not supported by the
display's specifications (1280 × 1024 or less).
I N FORMA T I ON
Ou t o f R a n g e
R e s o l u t i o n > 1
If "No Input Signal" appears on the screen
This indicates that no signal is being input via the currently
selected connector.
I N ORMA T I ON F
N o I n p u t S i g n a l
Go t o P o w e r S a v e
34
DV I - D : P C 1
/ X XXH z
DV I - D : P C 1
2 8 0 X 7 6 8
DV I - D : P C 1
2 8 0 X 1 0 2 4
DV I - D : P C 1
If "Cable Disconnected" appears on the screen
This indicates that the video signal cable has been disconnected
from the currently selected connector.
I N ORMA T I ON F
C a b l e D i s c o n n e c t e d
If "Power will be turned off by off timer soon."
appears on the screen
This indicates that the power provided to the display will be
turned off by off timer in 1 minute.
If "Power will be turned off by auto shut off soon."
appears on the screen
This indicates that the power provided to the display will be
turned off by auto shut off timer in 1 minute.
If "Feature Not Available" appears on the screen
This indicates that the function which you have attempted to
operate is not available.
DV I - D : P C 1
