3M™ Adflo™ Battery and Battery charger
USER INSTRUCTIONS
Please read these instructions in conjunction with other
relevant 3M User instructions and Reference leaflets
where you will find information on approved combinations/
classifications, spare parts and accessories.
SYSTEM DESCRIPTION
The 3M Adflo Battery Charger is designed to charge Li-ion
batteries for use with 3M Adflo Powered Air Respirator.
WARNING
Proper training, use and maintenance are essential.
Failure to follow all instructions on the use of these
products can lead to severe or life threatening illness,
injury or permanent disability.
For suitability and proper use follow local regulations,
refer to all information supplied or contact a safety
professional/3M representative (local contact details).
Particular attention should be given to warning
statements where indicated .
APPROVALS
These products are in conformity with the European Directive
2014/30/EU (EMC - Electromagnetic Compatibility) and the
Low Voltage Directive (LVD 2014/35/EU) and 2011/65/EU
(RoHS - Restriction of the use of Hazardous Substances).
LIMITATIONS OF USE
Only use with original 3M™ spare parts and
accessories listed in the reference leaflet and within the
usage conditions given in the Technical Specifications
The use of substitute components or modifications
not specified in these user instructions might seriously
impair protection and may invalidate claims under the
warranty or cause the product to be noncompliant with
protection classifications and approvals.
The product must not be used in flammable or
explosive environments.
Always correctly use and maintain the product according
to these instructions. Failure to do so may cause fire
or explosion or could adversely affect respirator
performance and result in injury, sickness or death.
Do not open,crush, disassemble, dispose of in fire,
heat above 60°C or incinerate.
To avoid damage to the equipment do not use solvents
for cleaning. Do not immerse in water or spray directly
with liquids. Do not wipe the electrical contacts.
EQUIPMENT MARKING
Markings on the equipment.
= Read the instructions before use
= Shall be disposed of as electrical and
electronic waste
= Recycle
= Do not allow contact with water. Protect
against moisture
= Do not expose to fire
= Do not store outside recommended
temperature range
= For indoor use only
= recharge after each use, when stored
recharge every six months
PREPARATION FOR USE
Check that the equipment is complete (see fig A:1),
undamaged and correctly assembled, any damaged or
defective parts must be replaced before use.
All new batteries must be charged before and after each
use (see operating instructions).
OPERATING INSTRUCTIONS
3M Adflo Powered Air Respirator has a three bar battery
indicator (see fig B:1) showing remaining capacity. When
the last bar starts flashing and an audible warning is
heard, less than 5% battery capacity is remaining. The
warning sound will change noticeably after a while and 3M
Adflo Powered Air Respirator will turn off automatically.
See Fault finding chapter for details.
Replacing the battery on the 3M Adflo Powered Air
Respirator (see fig D:1). Replace the battery and gently
pull the batterypack to confirm it is locked in place.
Battery charging
The charger is intended for indoor use only, protect
against moisture. Both the standard and heavy duty
battery will be fully charged in about 4-5 hours depending
on residual capacity.
The battery can be charged when installed in 3M Adflo
Powered Air Respirator, or separately (see fig C:1) 3M Adflo
Powered Air Respirator must not be used while charging.
Recommended temperature during charging is between
0 to +40°C. If the charger indicator light will not light up
when connecting the charger to the battery, please check
cords and connectors.
The battery charger is designed for fast charging of
3M Adflo Li-ion batteries with capacity 10.8V/32Wh to
10.8V/48 Wh.
Do not charge batteries with unapproved chargers,
in enclosed cabinets without ventilation, in hazardous
locations, or near sources of high heat.
Do not use, charge, or store batteries outside the
recommended temperature limits.
Mode Description
Standby Yellow per-
manent on
Pre-charge Yellow flash-
ing slow
Waiting Yellow
for correct and Green
temperature alternating
1ï/
LED Indication
Yellow
Green
Yellow
Green
Yellow
Green
