AC CONVENIENCE OUTLET
Any electronic device that operates on 120 volts, 60Hz and draws less than 3 amps or 360 watts may be plugged into the
convenience outlet. This outlet is especially useful for powering units housed in the internal rack space such as multi-effects or
rack tuners. The convenience outlet is not available on EU models.
It should be noted that some appliances such as fluorescent lights can cause interference or noise to be induced in the Super
Redhead.

SPECIAL FEATURES

FRONT COVER/ANGLE STAND
The Super Redhead's front cover was designed to serve two main purposes: to protect the electronics and speakers during
transport, and to double as a stand. To use the cover as an angled stand, remove the cover and place it in the desired location
(carpet side up). Next, remove the caster wheels from the bottom of the unit and place it carefully on the cover/angle stand.
You now have an angled amplification system that still couples the low end to the floor. Since all things have their limits, we do
not suggest using the cover/angle stand as a ramp.
BUILT-IN RACK SPACE
The single rack space directly below the Super Redhead's chassis is included for your convenience and is designed to accept
any standard single rack space unit (19" wide x 1.75" high).
REMOVABLE CASTERS
The Super Redhead comes with removable caster wheels for easy transportation. To remove the caster wheels, simply turn
the unit on its side and pull them out from the caster sockets. This will be necessary if you plan to use the cover/angle stand
during practice or performance.
SPRING-LOADED RUBBER-GRIP HANDLES
The handles on either side of the Super Redhead were chosen for their "rattle free" properties and the extra-thick rubber
padded grips. The handle placement allows for near perfect balance (meaning the unit should not tilt forward or backward
when carried).
THE TOP
Almost every musician we talked to told us that at some time or another they were going to end up sitting on the amp. With
this in mind, we would like you to know that we spent a great deal of time and effort to remove all mounting screws, vents and
other obstacles from the top of the combo and covered it with carpet just to make these times more comfortable for you.
Enjoy.
REGARDING COMBO AMPLIFIERS
The SWR Super Redhead has been designed with a robust 350-watt power amp, capable of driving its own speaker comple-
ment as well as cleanly driving an extension cabinet. When used by itself, a large amount of headroom is available in the Super
Redhead's power amp, which provides two important benefits: 1) A cleaner signal and better sound; 2) A power amp that oper-
ates at lower temperature, thereby prolonging component life.
However, because "combo" amplifiers such as the Super Redhead are designed as "all-in-one," self-contained units (i.e., incorpo-
rating both power and speaker sections), some players are under the impression that they should be able to turn all controls
to maximum without fear of speaker damage, distortion, etc. This is simply not the case. The Super Redhead will not overpow-
er its internal speaker section when run properly and in accordance with the operating instructions in this manual. However,
damage to the internal drivers may occur if the amplifier section is driven into clipping for long periods of time. Please be
aware of this possibility and turn down your Master Volume control if you hear distortion or notice that the Power Amp Clip LED
is constantly lighting during operation.
14 • SUPER REDHEAD
