TROUBLESHOOTING GUIDE

If your Discmaster 8.0 is not operating properly, disconnect the power and
check all connections using the notes in this handbook. If problems persist,
the checklist below may help.
If you are in any doubt, consult your dealer.
No picture or sound (all discs)
Switch off the power to the system and check that connections have been
correctly made from the Discmaster 8.0 to the TV, amplifier or surround
decoder.
Check that all equipment is switched on and that the correct input is selected
at the TV, amplifier or surround decoder.
Picture breaking up, incorrect colours or corrupted
The display video mode selected may not be supported by your monitor. Press
the N/P button to switch to basic video mode (NTSC). Press N/P again to
switch to basic video mode (PAL).
The S-Video output may be switched on while watching another video output.
If this is the case, switch off the S-Video output.
Disc Spinning with no sound
Check in the SETUP menu that the correct audio mode is selected for your
system and connections.
Region warning displayed when a disc is loaded
Check that the region symbol on the disc matches the region symbol on the
rear panel of the player (number with a globe symbol). To avoid this problem
ensure that discs are only purchased in the same global region as the player.
DVD picture stops and jumps to another scene
The disc may be dirty or badly scratched. Try playing another disc. If the other
disc plays ok, try cleaning the 1
st
NOTE:- Some discs feature dual layers. Playback will pause momentarily
whilst the player changes layer. This will only happen once during playback of
such discs.
A DVD disc does not play from the beginning
If this DVD is the last disc you played, the resume feature will continue from
this point when next used. Press STOP twice to return to the start of the DVD.
No Remote Operation
The handset batteries may need to be replaced:
Remove the battery compartment cover located underneath the unit. Remove
the batteries and replace with new ones carefully noting the orientation
marked in the bottom of the battery case.
The batteries in the unit should only be replaced with new batteries type AAA
(I.E.C. LR03).

Laser Product

This label on the rear panel tells
you that the unit contains a Laser
component. Opening this unit will
expose the user to radiation from
the laser beam.
WEEE
This logo means that this product is not to be disposed of
with your household waste. This product should be handed
over to a designated collection point to be recycled. Your
cooperation in the correct disposal of this product will
contribute to the effective usage of natural resources. For
more information on collection points, contact your disposal
service or City Hall.
8
disc.

WARRANTY

The warranty card enclosed should be completed by the purchaser
and returned to CYRUS or its Distributor within 8 days of purchase.
No Dealer or Distributor may vary the terms of this warranty which is
personal to the original Purchaser and is not transferable.
Please retain the sales receipt as proof of purchase.
Warranty claims must wherever possible be made through the Dealer
from whom the equipment was purchased.
This warranty excludes:
•
Damage caused through neglect, accident, misuse, wear and
tear, or through incorrect installation, adjustment or repair by
unauthorised personnel. Any unauthorised servicing will result in
loss of guarantee.
•
Liability for damage or loss occurring in transit to or from the
purchaser.
•
Consequential damage, loss or injury, arising from or in
conjunction with this equipment.
Equipment for attention under warranty should be consigned return
carriage paid. If returned equipment is found to comply with the
published specification, CYRUS reserves the right to raise a charge.
The above conditions do not affect your statutory rights as a
consumer.

SPECIFICATIONS

Power Supply
Voltage............................................................................As plate on rear of unit
Power Consumption
Playing .........................................................................................................12W
Standby..........................................................................................................3W
Safety Requirements ..................................................................................... CE
Enclosure
Dimensions (WxHxD) ............................................................215 x 75 x 365mm
Weight........................................................................................................2.6Kg
Material ..................................................................................... Die cast chassis
Analogue Audio Performance
Audio Output Level ...............................................................................2.0V rms
Output Impedance ....................................................................................300
Frequency Response...................................................................... 20Hz-20kHz
Channel Separation ..................................................................>100dB @ 1kHz
SNR (using silent track) ......................................................................... >97dBA
THD @ -10dB ......................................................................................... 0.015%
Digital Audio Performance
PCM Output compatibility ...........................................................44.1k, 48k, 96k
Surround output compatibility ......................................................... Dolby Digital
Output level.............................................................................................0.5Vp-p
Output Impedance ......................................................................................75
Video Performance
Output formats ......HDMI Digital, Component video, S-Video (Y/C), Composite
Output level........................................................................................... 1V pk-pk
Output Impedance ......................................................................................75
Cyrus reserves the right to change all specifications without notice. E &OE
User Instructions
Ω
>75dB@20kHz
Ω
VGA, SVGA, XGA, SXGA
Ω
