Cyrus Discmaster 8.0 Gebrauchsanleitung Seite 6

User Instructions
The Discmaster 8.0 is configured to match your system through an on-screen menu system. To access the menu system, press the SETUP key
control. Navigate the menu options with the CURSOR keys, press the OK key to make selections.
Sound Digital Output
SETUP
Stereo
Speaker setup
LPCM output
Pro Logic II
Display TV system
TV image
S-Video
Brightness
HDMI mode
Language Player menus
Disc menus
Audio
Subtitles
Lock Enter Password
Change PWD
Ratings Limits
Default
*Note:- The functioning of the Discmaster 8.0 Parental Control system depends on suitable software coding being available on the DVD disc. Cyrus cannot therefore
guarantee functioning of the Parental Control system and denies any liability associated with unintended watching of disc content. If in doubt, please make sure the
disc plays according to your Parental Control settings before allowing your children access.
GB
GB
Discmaster 8.0 Menu system
Check this box to enable Dolby Digital audio signals from the Digital output. If you have a stereo
Dolby Digital
DAC, uncheck this box.
Check this box to enable DTS audio signals from the Digital output. If you have a stereo DAC or a
DTS
surround decoder which is not compatible with the DTS format, uncheck this box.
Check this box to mix down multi-channel programs if you are using the internal surround sound
decoder to drive a system with two speakers.
Select this option to display the settings for system speaker size if you are using the internal
surround-sound decoder. Left and Right Front speakers may be set to Large or Small. The Center,
Speakers
Left and Right Surround speakers may be set to Large, Small or Off. The Subwoofer may be
switched On or Off. Set Small for satellite or small stand-mount speakers. Set Large for floor-
standing or larger stand-mount speakers. Set Off if you do not have a speaker in that location.
If you are using the Discmaster 8.0 surround sound decoder, select this option to set the distance
Distance
you sit from each speaker. Distances can be adjusted from 1m to 6.6m.
If you are using the Discmaster 8.0 surround sound decoder, select this option to set the volume
trims for each speaker. Trim adjustments will reduce the level from a particular speaker, so if you
Volume
are sat close to the surround speakers (for example), you can reduce the level from these until they
match the front speakers.
This setting enables 96k sample rate via the PCM digital output when this higher quality source
material is available. Set to 96k if you have a surround sound decoder or DAC that is compatible
with 96k programs, otherwise set to 48k.
Choose one of the five options available for the internal surround sound decoder. DSP mode off will
disable the internal Pro Logic II decoder, Emulation will enable original Pro Logic '4.1' decoding,
Music will enable the Pro Logic II decoder, optimised for playing music, Movie will optimise the Pro
Logic II decoder for playing movies, Matrix is a simpler decoding option.
Choose a suitable resolution for your monitor from the list of available resolutions. NOTE:- Some
monitors will not support all resolution settings, so check your monitor handbook before changing
this setting.
Select the screen shape of your TV/monitor. Choose 4x3 Letterbox to show the full picture width on
a 4x3 TV with black bands top & bottom. Choose 4x3 Standard for a full-height picture on a 4x3 TV,
but losing the left and right picture edges. Choose 16x9 if you have a Widescreen TV.
Select 'on' if you have used the S-Video connection to your TV.
This option enables the brightness of the picture from the Discmaster 8.0 to be adjusted to match
the brightness of off-air broadcast.
With this menu option, the signal format for the HDMI output can be changed. Select the option that
gives the best picture performance from your monitor if you are using a digital HDMI connection.
With this menu option, you can choose between available menu language options.
The Discmaster 8.0 will always select the selected menu language when available on a disc.
The Discmaster 8.0 will always select the selected audio language when available on a disc.
The Discmaster 8.0 will always select the selected subtitle language when available on a disc.
Your password must be entered to reach the next menu level. The factory password is 8888. This
may be changed at the next menu level. Restoring default settings with the default menu option will
reset to the factory password.
Use this menu option to change your password for access to ratings limit settings.
Ratings limit settings restrict the rating of DVD disc that may be played. Use this menu option to
change your password for access to ratings limit settings.*
Restores all settings to the factory default. Volume is set to maximum ( NOTE:- Caution is required
to reduce this setting before playing a disc if your Discmaster 8.0 is connected directly to power
amplifiers). Dolby Digital and DTS digital outputs are enabled. Speakers are all set to large size at a
distance of 3.3m (10ft) with the subwoofer switched on. Video is set for 480P with a screen size of
4x3 Letterbox. HDMI is set to RGB/60Hz. All language options are set to English.
Cyrus Discmaster 8.0
on the remote
