Frame and equipment supplied

The type key can be seen on the name plate. For Axial fans, it contains the following data:
Es:
VORT JET-R 560/2:
Serie: VORT JET-R
Nominal diameter: 560 mm
N. of poles: 2
VORT JET-R:
• These are available in two versions: fans with thrust equal to 100 N and fans with thrust equal to 50 N
• Hot deep galvanized sheet metal casing
• The electrical connection box (IP 67) is installed outside the product.
• Electrical motors with IP 55 and F class insulation
• 230 V, 1 phaze, 50 Hz and 400 V, 3 phase, 50 Hz
• When designing a system, radial fans allow for a reduced number of required axial fans and therefore the costs of wiring
and installation
• The reversed rotor blades of radial fans help reduce the phenomena of air turbulence
• The maximum height of radial fans is 335 mm and so they are ideal for the design of ventilation systems installed in
spaces with reduced height
• The fans are tested and approved at a temperature of 300°C for 2h in compliance with standard EN 12101-3
10
VORT JET-R XXX/Y
N. of poles
Nominal diameter
Name of the series
