Radio Operation - Telefunken RD1003 Gebrauchsanweisung

4.4 Software version
For each mode, DAB and FM, press and hold the Menu/Info (5) button. Scroll with the Prev. (8)
„
or next (6) button to "System" and confirm with the Select/-Volume+ (4) button. Go now with the
Prev. (8) or next (6) button to the option "SW version" and confirm with the Select/-Volume+ (4)
button. Then the software version is displayed in the display (3).
Press again the Menu/Info (5) button and release it to return to "System" or return to the mode
„
display with another keypress.
4.5 Setting backlight of the display
Follow the instructions below to select the backlight menu in power-on mode. This section
„
explains each setting.
Press and hold the Menu/Info (5) button.
„
When "Scan Setting" (FM) is displayed on the display (3), press either the Prev. (8) or next (6)
„
button to cycle through the menu options until you the menu option "System" is shown. Press the
Select/-Volume+ (4) button to select.
Use the Prev. (8) or next (6) button to select the option "Backlight" and press the Select/-
„
Volume+ (4) button.
Timeout
Use the Prev. (8) or next (6) button to select the option "Timeout" and press the Select/-Volume+
„
(4) button.
Press the Prev. (8) or next (6) button to cycle through the options 10, 20, 30, 45, 60, 90, 120, 180
„
seconds and "On".
Use the Select/-Volume+ (4) button to save the setting.
„
On level
Use the Prev. (8) or next (6) button to select the option "On level" and press the Select/-Volume+
„
(4) button.
Press the Prev. (8) or next (6) button to cycle through the options "Low", "Medium" or "High".
„
Use the Select/-Volume+ (4) button to save the setting.
„
Dim level
Use the Prev. (8) or next (6) button to select the option "Dim level" and press the Select/-
„
Volume+ (4) button.
Press the Prev. (8) or next (6) button to cycle through the options "Low", "Medium" or "High".
„
Use the Select/-Volume+ (4) button to save the setting.
„
4.6 Setting language
Follow the instructions below to set the OSD language.
Press and hold the Menu/Info (5) button in power-on mode.
„
When the option "Scan Setting" (FM) is displayed on the display (3), press either the Prev. (8) or
„
next (6) button to cycle through the menu options until you the menu option "System" is shown.
Press the Select/-Volume+ (4) button to select.
Use the Prev. (8) or next (6) button to search the option "Language" and press the Select/-
„
Volume+ (4) button.
Press the Prev. (8) or next (6) button to cycle through different language options: English,
„
Français, Deutsch and Italiano.
Use the Select/-Volume+ (4) button to save the setting.
„
5.

RADIO OPeRATIOn

5.1 Antenna
The appliance is equipped with a telescopic DAB/FM antenna (10), located on the back of the
„
appliance. Pull out completely the antenna and rotate to achieve the best reception.
5.2 Toggling between DAB and fM mode
When the appliance is switched on, press the Standby/Mode (1) button to toggle between DAB
„
(Digital Audio Broadcasting) or FM radio. The current selection is shown on the display (3).
When you switch on the radio again, it will tune automatically to the last selected radio station.
„
5.3 Automatic and manual tuning to DAB stations
Press Standby/Mode (1) to switch on the appliance.
„
When your radio is switched on for the first time, the radio enters automatically DAB mode and it
„
starts an automatic full scan for DAB radio stations. The radio scans all available stations.
The initial scan will take a few minutes. A bar diagram shows the progress of the scan on the
display (3). After the scan, the clock will be set automatically when DAB stations are available and
the radio will display the name of the first station in the sequence.
