The higher flow speed of the collector allows for heavy dirt
and smallest floating particles to be separated from the
³VXFNHGLQ DLU´
It is thus not necessary to buy dust bags.
The filters must be cleaned periodically.
CAUTION:
1HYHU ZDVK WKH ILOWHU LQ WKH ZDVKLQJ PDFKLQH
'R QRW XVH D KDLUGU\HU IRU GU\LQJ
2QO\ SXW WKH DSSOLDQFH EDFN LQWR RSHUDWLRQ ZKHQ DOO ILOWHUV
are completely dry and correctly assembled.
The Filter Unit
The filter unit is composed of:
‡ +(3$ ILOWHU
‡ &RDUVH ILOWHU
Proceed as follows to clean the filter unit:
1. Empty the dust container as described above. (Steps 1 - 5)
2. Disassembly of the filter unit
2.1 Press the dotted area of the button (1) to disconnect
the dust container from the motor housing.
2.2 Turn the cover of the dust container in the direction
Remove the cover.
2.3 Pull the filter unit from the dust container.
2.4 Turn the HEPA filter to remove it from the
coarse filter.
3. You can brush out the HEPA filter. In case of heavy
staining, clean the filters under running water.
4. Let the filters air-dry completely before refitting them!
5. Wipe the dust collector with a damp cloth and then wipe
it dry.
6. Assembly of the filter unit
6.1 The HEPA filter has 3 guide lugs. Set the largest guide lug
into the largest recess of the coarse filter.
Tighten the HEPA filter by turning it clockwise. It must
audibly engage.
.
