Overview of the Components / Delivery Scope
1. Button for unlocking / locking the
filter unit
2. LED charge indication
3. Multifunction button
4. Carrying handle
5. Socket for connection of the
power supply unit
6. Dust collector base plate
7. Dust collector with HEPA filter
8. Lock of the dust collector
9. Opener of the dust collector
10. Suction tube
11. Unlocking the floor nozzle
12. Lock of the brush roller
13. Floor nozzle with turbo brush
14. Unlocking for suction pipe or nozzle
attachment
15. Adapter
16. Combined crevice / brush nozzle
17. Wall holder
Not shown:
1 x Mains adapter
2 x Wall plug
2 x Screw
Unpacking the Device
1. Remove the device from its packaging.
2. Check the delivery scope for completeness.
3. Check the device for any transport damage, in order to
prevent hazards.
/ + / –
