8. Fitting and changing the Tec Comfort Set
Seat liner:
Undo the strap. For more information, follow the instructions in
section 9.
a.
Then pull the crotch belt through the opening in the seat liner.
b.
Fix the tab on the head end of the seat liner with the Velcro fastening on the backrest.
Guard rail cover:
c.
Fit the cover around the guard rail and secure it in place with the Velcro fastening.
9. Adjusting the leg rest
To adjust the leg rest, press in the buttons on both sides and then adjust the height.
Let go of the buttons again so that the leg rest clicks into place.
10. Fastening the harness
a.
To fasten the harness, bring the top two plastic catches together and interlock them.
b.
Then insert the interlocked catches into the bottom part of the fastening.
Adjust the harness to a setting where the baby is held in the correct
11. Unfastening the harness
To open the harness, press the button on the side.
CAUTION: Always use the shoulder harness and lap belt together.
12. Adjusting the seat unit
To adjust the seat unit, press and hold down the catches on both sides of the seat unit and adjust the
height of the seat. When you have reached the required position, let go of the catches to allow the seat to
remain in that position.
Carrycot
13. Opening the carrycot
Lift the side panels of the carrier.
Extend and secure the side panels by pushing the two retainers outwards into the mountings.
Make sure that the retainers are securely engaged.
14. Attaching the cot bumper
Lay the bumper in the cot, folding the top part over the edge of the carrycot.
Fasten the four press studs on the rear.
15. Attaching the hood to the cot bumper
Fasten the four press studs on the bottom of the hood onto the bumper.
