GB

Specifications

Supply voltage
Power consumption
Type of protection
Operating frequency
Minimum flush duration
Maximum flush duration
Electrical test data
Software class
Contamination class
Rated surge voltage 2500 V
Temperature of ball pressure test 100 °C
The test for electromagnetic compatibility (interference
emission test) was performed at the rated voltage and rated
current.

Connecting to the power supply

• Connect the power supply line 2 x 1.5mm² (electrician)
• Only water-resistant round cable with max. outside diameter
of 5.0 to 6.5mm must be used.
• Electrical installation work must only be performed by a
qualified electrician. This work must be performed in
accordance with regulations IEC 364-7-701-1984
(corresponds to VDE 0100 Part 701) as well as all national
and international regulations.
• The voltage supply must be separately switchable.
• Regarding 38 511: The mounting box must be connected to
the earthing clamp and the earthing cable at the designated
locations (see Fig. Page I).
• Regarding 38 387: Connect the earth cable
(see Fig. Page I).
For latest prices and delivery to your door visit MyTub Ltd - 0845 303 8383 - www.mytub.co.uk - info@mytub.co.uk
230 V AC, 50/60 Hz
3.2 VA
IP 54
24.075 GHz – 24.175 GHz
0.5 s
12s
A
2

Safety notes

• Installation is only possible in frost-free rooms.
• Electronic fittings are only suitable for indoor use.
• In the case of damage to the external transformer and
control unit connection cable, this must be replaced by the
manufacturer or his customer service department or an
equally qualified person, in order to prevent a hazard.
• When cleaning the fitting (the urinal) it must be ensured that
the tile frame behind which the electronics are installed is
not sprayed directly with water.
• In order to provide optimum water resistance, the tile frame
must be sealed.
• Use only original spare parts
Approval and conformity
0682
! ; 0700 !
This product conforms to the requirements of the relevant EU
guidelines.
The conformity declarations can be obtained from the following
address:
GROHE Deutschland Vertriebs GmbH
Zur Porta 9
32457 Porta Westfalica
Type approvals
The system may only be operated in the following countries:
Germany, France, Belgium, Spain, Italy, Netherlands,
Denmark, Norway, Switzerland, Austria and Portugal.
