• Contact with the unprotected saw chain (injury by cutting)
• Expulsion of parts of the saw chain
• Expulsion of parts of the cut items
• Damage to hearing
• Breathing in of particles from cut items
• Contact with petrol/oil
For this reason, it is essential that this chain saw is always used with the additional personal
protective equipment as shown on the machine and described in these operating instructions.
It is also necessary to observer the safety notes.

Your device at a glance

► P. 3, item 1
1. Handle
2. Handle
3. On/off switch
4. Tank cover (for fuel-oil mixture)
5. Tank cover (for saw chain oil)
6. Pull-starter
7. Saw chain
8. Saw rail
9. Cover for air filter and spark plug

Unpacking and assembly

Unpacking

Unpack the device and check for completeness.

Scope of delivery

• Instructions for use
• Chain saw
Note:
If one of the parts should be missing or damaged, please contact the vendor.

Assembly

10. Hand guard (trigger for chain brake)
11. Chain tensioning screw
12. Fastening nuts (for saw rail)
13. Chain wheel guard
14. Choke handle
15. Fuel pump
16. Throttle
17. Throttle block
18. Hanging mechanism
• Protective cover for saw rail
• Tool set
