Machine components
EN
1 Handle
2 Button for disk locking
3 Hose connector Ø 35 mm
4 Dust hood
5 Lamellar ring
6 Flange nut
7 Diamond cup wheel
8 Coupling nut
9 Button
(to turn the main handle)
10 Lock switch
11 ON/OFF switch
12 Ventilation openings
13 Main handle
14 Mains cable with plug
15 Electronic-signal-indicator

Intended use

The concrete grinder is designed for grinding and re-
moving concrete, screed and coatings.
Only for commercial use in trade and industry.
Observe all safety information, instructions, figures
and data which you received with this device.
Equipped with the suitable cup wheel for the respec-
tive application, the tool is designed for dry grind-
ing, deburring and smoothing of uneven areas on
concrete surfaces, for removing formwork seams,
limewash and cementitious adhesive residue during
re-tiling. With the correct cup wheel it is also suit-
able for removing thermoplastic protective coatings
and adhesive residue. The lamellar ring may become
clogged up when working on thermoelastic materials.
Only use cup wheels recommended by the manufac-
turer. The use of other cup wheels can overstrain the
power tool, damaging the bearings and putting the
operator at risk.
The concrete grinder may only be used in connection
with a suitable dust extraction device of dust class
"M".
The user is liable for any damage caused by improper
use.
CE - Declaration of conformity
We declare under our sole responsibility that
this product complies with the following stand-
ards and standard products: EN 55014, EN 61000,
EN 60745-1:2009 + EN 60745-2-3:2011+A2:2013
+A11+A12:2014 in accordance with directives till
19.04.2016: 2004/108 EC; from 20.04.2015 2014/30/
EC; 2006/42 EC, 2011/65/EC.
Gaimersheim, 08.11.2017
Alexander Essing
Managing Director
Technical documentation can be requested from:
Collomix GmbH
Dept. Technical Development
Daimlerstr. 9, 85080 Gaimersheim, Germany
Technical data
Concrete grinder
Rated input power
Voltage:
Frequency:
Idling speed 1. Gear:
Cup wheel diameter:
Weight without disk:
Protection class:
Noise/ vibration levels
Measuring values determined in accordance with EN
60745.
The A-rated noise level of the device is typically:
CMG 2600
Triaxial total vibration value
CMG 2600

WARNING:
The measurement values stated apply for new de-
vices. Noise levels and vibration values will change in
daily operation.

NOTE
The vibration level stated in this manual was meas-
ured in a standard test procedure in compliance with
EN 60745, and can be used for comparisons of power
tools. It can also be used for a preliminary assessment
of vibration stresses. The stated vibration level is rep-
resentative for the main applications of the power
tool. The vibration level may deviate where the power
tool is utilised for other applications and other tool
inserts, or where insufficient maintenance affects per-
formance. Vibration stresses may then be significantly
higher for the duration of tool utilisation.
For an exact estimation of the vibration stresses, de-
activation times of the device must be taken into con-
sideration, as well as times during which the machine
is running, but is not actually in operation. These as-
pects may significantly reduce vibration stresses over
the entire work time.
Rev. 3 / 10
Acoustic pressure Sound power
L [dB(A)] L
pA WA
94 dB(a) 105 dB(A)
Uncertainty K = 3 dB
Emission value a [m/s ]
2
n
6,7 m/s
2
Uncertainty K = 1.5 m/s
2
CMG 2600
2600 Watts
230-240 Volt
50/60 Hz
6600 min
-1
180 mm
6,8 kg
q / II
