Intended Use - Collomix CMG 2600 Originalbetriebsanleitung

Machine components
EN
1 Handle
2 Button for disk locking
3 Hose connector Ø 35 mm
4 Dust hood
5 Lamellar ring
6 Flange nut
7 Diamond cup wheel
8 Coupling nut
(to turn the main handle)
9 Button
10 Lock switch
11 ON/OFF switch
12 Ventilation openings
13 Main handle
14 Mains cable with plug
15 Electronic-signal-indicator

Intended use

The concrete grinder is designed for grinding and re-
moving concrete, screed and coa琀椀ngs.
Only for commercial use in trade and industry.
Observe all safety informa琀椀on, instruc琀椀ons, 昀椀gures
and data which you received with this device.
Equipped with the suitable cup wheel for the respec-
琀椀ve applica琀椀on, the tool is designed for dry grind-
ing, deburring and smoothing of uneven areas on
concrete surfaces, for removing formwork seams,
limewash and cemen琀椀琀椀ous adhesive residue during
re-琀椀ling. With the correct cup wheel it is also suit-
able for removing thermoplas琀椀c protec琀椀ve coa琀椀ngs
and adhesive residue. The lamellar ring may become
clogged up when working on thermoelas琀椀c materials.
Only use cup wheels recommended by the manufac-
turer. The use of other cup wheels can overstrain the
power tool, damaging the bearings and pu琀�ng the
operator at risk.
The concrete grinder may only be used in connec琀椀on
with a suitable dust extrac琀椀on device of dust class
"M".
The user is liable for any damage caused by improper
use.
CE - Declaration of conformity
We declare under our sole responsibility that
this product complies with the following stand-
ards and standard products: EN 55014, EN 61000,
EN 60745-1:2009 + EN 60745-2-3:2011+A2:2013
+A11+A12:2014 in accordance with directives till
19.04.2016: 2004/108 EC; from 20.04.2015 2014/30/
EC; 2006/42 EC, 2011/65/EC.
Gaimersheim, 08.11.2017
Alexander Essing
Managing Director
Technical documentation can be requested from:
Collomix GmbH
Dept. Technical Development
Daimlerstr. 9, 85080 Gaimersheim, Germany
Technical data
Concrete grinder
Rated input power
Voltage:
Frequency:
Idling speed 1. Gear:
Cup wheel diameter:
Weight without disk:
Protec琀椀on class:
Noise/ vibration levels
Measuring values determined in accordance with EN
60745.
The A-rated noise level of the device is typically:
CMG 2600
Triaxial total vibra琀椀on value
CMG 2600

WARNING:
The measurement values stated apply for new de-
vices. Noise levels and vibra琀椀on values will change in
daily opera琀椀on.

NOTE
The vibra琀椀on level stated in this manual was meas-
ured in a standard test procedure in compliance with
EN 60745, and can be used for comparisons of power
tools. It can also be used for a preliminary assessment
of vibra琀椀on stresses. The stated vibra琀椀on level is rep-
resenta琀椀ve for the main applica琀椀ons of the power
tool. The vibra琀椀on level may deviate where the power
tool is u琀椀lised for other applica琀椀ons and other tool
inserts, or where insu昀케cient maintenance a昀昀ects per-
formance. Vibra琀椀on stresses may then be signi昀椀cantly
higher for the dura琀椀on of tool u琀椀lisa琀椀on.
For an exact es琀椀ma琀椀on of the vibra琀椀on stresses, de-
ac琀椀va琀椀on 琀椀mes of the device must be taken into con-
sidera琀椀on, as well as 琀椀mes during which the machine
is running, but is not actually in opera琀椀on. These as-
pects may signi昀椀cantly reduce vibra琀椀on stresses over
the en琀椀re work 琀椀me.
Rev. 3 / 10
Acous琀椀c pressure
Sound power
[dB(A)]
L L
pA WA
94 dB(a) 105 dB(A)
Uncertainty K = 3 dB
Emission value a ]
[m/s
2
n
6,7 m/s 2
Uncertainty K = 1.5 m/s
2
CMG 2600
2600 Wa琀琀s
230-240 Volt
50/60 Hz
6600 min
-1
180 mm
6,8 kg
q / II
[dB(A)]
