Connection between devices

The device is equipped with a lockable power input connector. Afix the power cord and turn it to the right
until it locks. Plug the power cord into a grounded electrical outlet that matches the rated voltage of the
machine.
On the rear panel, there is a lockable mounted socket (Power Out). Connect the output with the mains input
of the next fixture until all fixtures are connected.
Please note: A maximum of 8 devices may be linked together. After every 8 devices, the fixtures must have

Master/Slave-operation

The master/slave-operation enables that several devices can be synchronized and controlled by one master-
device.
On the rear of the LED THA-120PC Theater Spot you can find an XLR-jack (DMX Out) and an XLR-plug
(DMX In), which can be used for connecting several devices.
Choose the device which is to control the spotlights. Set the desired Master-mode on the master-device.
This device then works as master-device and controls all other slave-devices, which are to be connected to
the master-device via a balanced microphone lead. Connect the DMX out connectors with the DMX input
plug of the next device.
Set the Slave-mode on every slave-device.
Press the MODE button to select the SLAVE mode. The devices set in this manner can now be controlled by
the master unit.
Please see further instructions under Operation.

Connection with the mains

Connect the device to the mains with the enclosed power supply cable.
The occupation of the connection-cables is as follows:
Cable Pin
Brown Live
Blue Neutral
Yellow/Green Earth
The earth has to be connected!
If the device will be directly connected with the local power supply network, a disconnection switch with a
minimum opening of 3 mm at every pole has to be included in the permanent electrical installation.
The device must only be connected with an electric installation carried out in compliance with the IEC-
standards. The electric installation must be equipped with a Residual Current Device (RCD) with a maximum
fault current of 30 mA.
Lighting effects must not be connected to dimming-packs.
The device is equipped with a lockable power input connector. Plug in the power cord and turn it to the right
until it locks. Plug the power cord into a grounded electrical outlet that matches the rated voltage of the
machine
a renewed connection with the power mains.
International
L
N
23/28 00099958.DOC, Version 1.0
