REMOTE CONTROL INSTRUCTIONS

1. Installation Instructions

Remote bracket can be installed in any vertical plane.

2. Application Instructions

● Characteristics of emitter
1. Power supply: 12V Li-battery, model CR23A
2. Protecting rank: IP 20
3. Working temperature: -20+55
4. The emitter stops automatically after transmitting the same command for 8 seconds.
3. Operation Instructions
1. Press the button UP (▲) on the emitter, the awning expands;
Press the button Down (▼), the awning closes;
Press the middle button STOP, the awning then stops its action
2. To recognize through receiver Shut off the power of receiver, press both button UP (▲)
and DOWN (▼) on the emitter, then turn on the power of receiver, the receiver will
make "du..du..du..du" continuous sound, till it makes a long beep.
Loosen the button.
The address information of the emitter will be then stored in the receiver and in the
meantime the emitter will end its program setting mode automatically (If the address of
emitter in the receiver is over 10, it beeps 6 times, which indicates that the emitter
cannot be recognized any more)
