STEP 5
Your Awning is now ready to be secured to the wall brackets.
With at least 2 people, carefully lift both ends of the awning unit until the torsion bar slides
into the wall brackets.
Remove the restraint straps from around the awning unit if not already done so.
The awning should be fixed as in the following diagrams.
NOTES
It will be necessary to use 2 sets of ladders or step stools to lift the awning unit to the
required height.
Ensure the steps or ladders are safely positioned and well secured to avoid slipping or
injury.
Always use ladders or steps of the appropriate rating for the job.
WARNING
This Awning unit is heavy; do not attempt to lift this unit onto the wall brackets
without assistance from a second person.
EN
Cross section
of wall
Retaining
nut and bolt
11
KEN001VKM
v03 • 07.09.2017
Cross section
of wall
