STEP 4
After inserting the wall bolts, slide the washers over the bolt heads followed by the wall
bracket.
Slide the remaining bolt washers over the bolt heads and tighten the 17mm nuts securely.
NOTE
It might be necessary to tap the wall bolts into position with a wooden faced mallet as the
fit might be fairly tight.
Avoid using a metal faced hammer as this might damage the threads on the top of the bolt
shaft.
If the bolts require tapping into the wall with a mallet, it is recommended the nut be loosely
screwed on top of the bolt first (almost flush with the end of the bolt shaft) as this will
prevent damage to the threads on the bolt shaft during insertion.
Tighten the wall bolt nuts securely with a 17mm hexagonal spanner.
It is better to use a closed ended spanner rather than an open ended spanner to avoid
spanner-slip damage to the nut.
When bolted into position, the brackets should be tight against the wall.
If any movement is detected, tighten the nuts.
DO NOT ATTEMPT TO FIT THE WALL BRACKETS TO LOOSE BRICKS OR
SURFACES THAT ARE NOT OF SOUND CONSTRUCTION.
ENSURE THE WALL BRACKETS ARE WELL BOLTED TO THE WALL TO
PREVENT THE
BRACKETS FROM FALLING FROM THE WALL WHEN THE AWNING IS FITTED.
