Operation

Menu Function Settings
Use the display and button to set different function, see the below diagram.
No. Display
DMX Mode, up/down monitor Address value from 001-512. When Address value is 001,
1 D001
mode is master-slave
*For normal use with DMX please set to IP01*
IP.01-IP.64 Fixture Subgroups, Function active when DMX Adress is 001.
2 IP.01
DMX adress 001+IP01= start address1, DMX adress 001+IP02= start address 009.
DMX Adresse 001+IP03= start address 17 etc.
select color，Press UP/DOWN to choose the macro definition of color(A1.01-A1.19).
3
A1.01
Can be Master mode.
Color jumping, Press UP/DOWN to choose the macro definition of color(A2.01-A2.19),
4 A2 will flash after you press ENTER, and then press UP/DOWN to adjust the
A2.01
speed(A2.01-A2.32). Can be Master mode.
Color gradient,Press UP/DOWN to choose the macro definition of color(A3.01-A3.19), A3
5 will flash after you press ENTER, and then press UP/DOWN to adjust the speed(A3.01-
A3.01
A3.32). Can be Master mode.
Sound Mode, Press UP/DOWN to choose the macro definition of color(A4.01-A4.19), A4
6 will flash after you press ENTER, and then press UP/DOWN to adjust the sensitivity of
A4.01
sound activate(A4.01-A4.04). Can be Master mode.
Strobe，Press UP/DOWN to choose the macro definition of color(A5.01-A5.19), A5 will
7
flash after you press ENTER, and then press UP/DOWN to adjust the speed(A5.01-A5.32).
A5.01
Can be Master mode.
Auto run
8
A6.01
Colour macro
9
A7.01
Red dimming, up/down change led brightness (00-255)
10
R255
Green dimming, up/down change led brightness (00-255)
11
G255
Blue dimming, up/down change led brightness (00-255)
12
B255
White dimming, up/down change led brightness (00-255)
13
W255
Function
