Inhaltszusammenfassung für Lightmaxx VEGA BAR QUAD
Seite 1
VEGA BAR QUAD LIG0015061-000 Bedienungsanleitung User‘s Manual...
Seite 2
Wichtige Sicherheitshinweise! Bitte vor Anschluss lesen! • Im Falle von Beschädigungen des Netzkabels muss dieses umgehend gegen ein Original Ersatzteil des Herstellers ersetzt werden. RISK OF ELECTRIC SHOCK DO NOT OPEN • Stellen Sie sicher, dass die Netzspannung nicht höher als die auf dem Gehäuse angegebene Spannung ist.
Herzlichen Glückwunsch zu Ihrem neuen LightmaXX LED BAR! Vielen Dank, dass Sie sich für ein Produkt von Lightmaxx entschieden haben. Durch ef- fiziente Entwicklung und ökonomische Produktion ermöglicht LightmaXX hochwertige Produkte zu einem fantastischen Preis. Bitte lesen Sie die Bedienungsanleitung sorgfältig, um über sämtliche Funktionen dieser LED Bar informiert zu sein und bewahren Sie diese zur späteren Verwendung auf.
Anschlüsse und Verkabelung 1: Safety Öse 4. DMX Output 2: Stromanschluss (IEC In) 5. Stromausgang/Link (IEC Out) 3. DMX Input 6. Display/Menü Funktionen der Fernbedienung Blackout: Alle LEDs aus SPR: Eingebaute Programme können via +/- angewählt werden BLACKOUT DIMMING Flash Modus, Geschwindigkeit kann via +/- variiert werden WHITE SELECT PROG FLASH...
Seite 6
Safety Instructions! Please read before connection and operation! • Ensure that the supply voltage does not exceed the voltage capacity indicated on the housing of the device. RISK OF ELECTRIC SHOCK • In case of failure of the device, please contact the distri- DO NOT OPEN butor and stop all operations of the device immediately.
Congratulations on your new LightmaXX LED Bar! Thank you for purchasing a LightmaXX product. Through efficient development and economical production, LightmaXX enables high-quality products at a fantastic price. Please read the operating instructions carefully, in order to be informed about all the functions of this LED Bar and keep them for future reference.
Cabling & Connections 1: Safety Eyelet 4. DMX Output 2:Power Connection (IEC In) 5. Power Output/Link (IEC Out) 3. DMX Input 6. Display/Menu Remote control Blackout: All LEDs off SPR: Integrated programs can be selected via +/- BLACKOUT DIMMING Flash Mode, Speed can be adjusted via +/- WHITE SELECT PROG FLASH...
4 Channel Mode Channel Value Description 000-255 000-255 Green 000-255 Blue 000-255 White 8 Channel Mode Channel Value Description 000-015 no function 016-023 024-031 Green 032-039 Blue 040-047 White 048-055 Red + Green 056-063 Green + Blue 064-071 Blue + White 072-079 Red + White 080-087...
Seite 11
16 Channel Mode Channel Value Description 000-255 Red 1 000-255 Green 1 000-255 Blue 1 000-255 White 1 000-255 Red 4 000-255 Green 4 000-255 Blue 4 000-255 White 4 20 Channel Mode Channel Value Description 000-015 no function 016-023 024-031 Green 032-039...
Seite 12
20 Channel Mode Channel Value Description 000-255 Red 1 000-255 Green 1 000-255 Blue 1 000-255 White 1 000-255 Red 4 000-255 Green 4 000-255 Blue 4 000-255 White 4...
Seite 14
VEGA BAR QUAD MUSIC STORE professional GmbH • Istanbulstr. 22-26 • 51103 Köln Tel: +49 221 8884-0 • Fax: +49 221 8884-2500 info@musicstore.de Subject to change without notice • Technische Änderungen vorbehalten...
