2. mounting of the enclosure
The RAYSTAT-CONTROL-10 can be installed indoor or outdoor�
Do not install the thermostat under the thermal insulation�
a. Wall mounting
Mount the enclosure using wall fasteners (screws) via the four,
4 mm ∅ holes�
B. mounting on a pipe
Pentair Thermal Management offers different support brackets (not
included) to mount the RAYSTAT-CONTROL-10 on a pipe: SB-100,
SB-101 or SB-110�
3. Wiring
Remove the terminal protection cover to access the terminals�
power cable:
Enter a single phase (230 Vac�) power cable through the M25 gland 2
(see drawing A ) and wire according to the wiring diagram (page 37)�
Wiring the heating cable can be done either:
A� Via junction box or contactor or when using RayClic with the cold cable
through the M25 gland 3 �
B� Directly into RAYSTAT-CONTROL-10�
In this case, the M25 gland 3 , which is delivered pre-mounted to the
RAYSTAT-CONTROL-10, is to be replaced by an appropriate kit�
Follow instructions supplied with the kit for installation�
important: For Voltage Free Operation, the wire links (W1) and (W2)
need to be removed� Failure to remove the wire links can result in
damage to the unit or to other connected equipment� Wiring of RAYSTAT-
CONTROL-10 to a remote alarm is optional through the M20 gland 4 � It
is strongly recommended to use a remote alarm for critical operations
(e�g� when extreme low temperatures (lower than –25°C) can be expected
or for critical processes)�
