4. DIP-SWITCH CODE (only version
Royal/53200)
The factory dip-switch code set for channel 1 is 0101010101 00.
If other remote controls are already stored on the receiver, the
dip-switch code of the keypad has to be set with the same
sequence of the one set on the dip-switch of the remote control.
The dip-switch of the remote control is made up by a series of 12
micro switches set to ON or OFF.
To set the same code on the keypad, it is necessary to key in a
code made up of 12 digits: those will be 0 or 1, depending on
the position of the micro switches on the remote control
-
micro switch set to ON = 1
-
micro switch set to OFF= 0
If the transmitter is single channel, the dip-switch to be set
coincides with the position of the 12 micro switches.
If the transmitter is two-channel and the key stored is 2, the
dip-switch code to be set coincides with the position of the 12
micro switches. If the key stored on the receiver is the key 1, the
dip-switch code coincides with the position of the micro switches
from 1 to 10 plus the 2 digit 00.
If the transmitter is four-channel, the dip-switch code to be
set coincides with the position of the micro switches from 1 to 10
plus 2 digits, which are:
•
00 if the key stored on the receiver is the key 1
(e.g. 1010101010 00)
•
10 if the key stored on the receiver is the key 2
(e.g. 1010101010 10)
•
01 if the key stored on the receiver is the key 3
(e.g. 1010101010 01)
•
11 if the key stored on the receiver is the key 4
(e.g. 1010101010 11)
If no transmitter has been stored on the receiver, the
dip-switch code can be set entering a random sequence of 12
digits 0 or 1.
OPERATIONS TO BE MADE ON THE KEYPAD
1. Key in # + PROGRAMMING CODE + #
Signalling: 1 BEEP of 1,5 sec. + L1 and L2 on for 1,5 sec.
2. Key in within a minute the KEY 4 + #
Signalling: 4 BEEPs + L1 and L2 flashing alternately
3. Key in the NUMBER OF THE CHOSEN CHANNEL + #
Signalling: 1 BEEP of 1 sec. + L1 and L2 flashing alternately
4. Key in the CHOSEN DIP-SWITCH CODE + #
Micro switch set to ON = 1
Micro switch set to OFF = 0
Signalling:
- 1 BEEP of 3 sec. + L1 and L2 on if the
operation is correct;
- short flashes of the LED if incorrect
DECLARATION OF CONFORMITY
V2 S.p.A. hereby declare that SIRMO-DIGIT equipment conforms
to the essential requirements established in the electromagnetic
compatibility directive
2004/108/CEE
electromagnetic compatibility
2006/95/EEC
electrical safety
99/5/EEC
directive radio
and that the following technical standards have been applied
EN 60950, EN 301 489-1, EN 301 489-3, EN 300 220-1
Racconigi, 11/02/2010
Legal representative, V2 S.p.A.
Cosimo De Falco
12
