MotionOrb™ EXT QRG
Length Setting
Length Setting
Options
Pixel Mapping
Personalities
The MotionOrb™ comes standard in a 2-meter length, but MotionOrb™ EXT can
be added to make the MotionOrb™ up to 4 meters long. Each orb string extension
is 1 meter long. The Length setting configures the MotionOrb™ EXT for the
number of orb strings attached.
To configure the MotionOrb™ EXT length, do the following:
1. Press <MENU> repeatedly until Length shows on the display.
2. Press <ENTER>. A length option (2M, 3M, 4M) shows on the display.
3. Press <UP> or <DOWN> until the desired length shows on the display.
4. Press <ENTER>.
5. Press <MENU>. The desired length stops showing on the display.
The MotionOrb™ functions correctly only if the Length setting matches the
total length of orb strings installed. For example, if the MotionOrb™ is set to
4M, but the actual length is only 2 meters long, the effects macros will not
display properly and the pixel mapping will not work.
The Length settings options in the MotionOrb™ menu are as follows:
Options
2M For the standard MotionOrb™ with no orb string extensions,
2 m total length
3M
For the addition of 1 MotionOrb™ EXT package, 3 m total length
4M For the addition of 2 MotionOrb™ EXT packages, 4 m total length
There is a different pixel mapping DMX personality for each length of
MotionOrb™, and those personalities are listed below.
Personality
2M mode - MotionOrb™ with a total of 11 orbs per string
DMX_165CH
(1 standard orb string and 1 bottom orb string; no extensions)
3M mode - MotionOrb™ with extensions for a total of 16 orbs per
DMX_240CH string (1 standard orb string plus 1 orb string extension, and 1 bottom
orb string)
4M mode - MotionOrb™ with extensions for a total of 21 orbs per
DMX_315CH string (1 standard orb string plus 2 orb string extensions, and
1 bottom orb string)
Because MotionOrb™ EXT is not used with the DMX_165CH DMX personality,
this Pixel Mapping diagram is not shown in this QRG.
To activate DMX mode and select the DMX personality, do the following:
1. Press <MENU> until Dmx shows in the display.
2. Press <ENTER> until DMX Mode shows on the top line of the display.
3. Use <UP> and <DOWN> until the desired DMX mode shows on the bottom
line of the display.
4. Press <ENTER>. Dmx shows in the display.
In pixel mapping mode there is a unique DMX address for each orb. The diagrams
on the next pages show these DMX addresses.
The Length setting must be set properly for pixel mapping to work. For
instructions about setting the length, see
Required Extensions/Total Length
Total Orbs Per String
Length
4
Setting.
