• Only use original monofilaments with 1,4 mm ø and
original spools.
• Never press the cutting head on the ground, when do-
ing this you brake the turned-on motor.
• Never hit the cutting head on a hard underground,
otherwise you will unbalance and damage the motor
shaft.

4. Before use

WARNING! Before assembly, make sure that the
line trimmer is switched off and unplugged.
Fitting the edging wheel (Fig. 2 and 3)
NOTE: Tank care when unwrapping both halves of edg-
ing wheel (7) not to discard the two assembly screws
(ST3×12mm) attached.
1. Align both halves of the edging wheel (7) onto the
line trimmer housing as shown (Fig.2).
2. Secure the edging wheel (7) in place with the two
screws Supplied using a Phillips head screwdriver
(Fig. 3).
3. When secured ensure that the edging wheel is free
to rotate On the housing.
Fitting the safety guard (Fig.4)
1. Slide the safety guard (9) in the recess under the
edging wheel (7) and align with the screw from
underneath with the One screws (ST4.2×15mm)
supplied (Fig.4) using a Phillips head screwdriver.
Note: The edging wheel (7) should rotate on the trimmer
housing and not come into contact with the safety guard
(9) when both parts are fitted correctly.
WARNING! Never use the line trimmer unless the
safety guard is properly fitted.
Fitting the auxiliary handle (Fig. 5)
1. Place the auxiliary handle (2) on the bracket and
adjust the angle to a comfortable position.
2. Insert bolt through the bracket and auxiliary handle
(2), screw the auxiliary handle locking knob onto the
bolt. Do not overtighten.

5. Preparing the line trimmer for use

WARNING! The line trimmer runs for a few sec-
onds after it has been switched off. Let the motor
come to a complete standstill before setting the
tool down.
Telescopic shaft adjustment (Fig.6)
1. The line trimmer shaft can be adjusted to suit the
height of the operator. Loosen the telescopic quick
lock (3).
2. Adjust the telescopic shaft (4) up or down to the
appropriate height. Tighten the quick lock (3). Once
adjustment is complete.
Adjusting the cutting head (Fig. 7)
By adjusting the cutting head angle to any of the 4 preset
angles the line trimmer can be used to trim under low
hanging branches and shrubs or garden furniture.
GB | Operating Instructions
Depress the head angle lock button (11) and adjust the
cutting head to the desired angle. Release the button
(11) and ensure that the cutting head locks in position.
Edging mode (Fig. 8 and 9)
In order to use the line trimmer as an edger, adjust as
follows:
1. Push the rotating head button (5) on the motor hous-
2. Release rotating head button (5), ensure shaft firmly
3. The trimmer can now be used for edging (Fig. 9).
Extension cord retainer (Fig.10)
To avoid detaching the extension cord always check
that it is attached to the cord retainer (b) before using
trimmer.
1. Make a loop with the extension cord and push it
2. Place the end of the loop round cord retainer (b) and
3. Connect the extension cord socket to the line trim-

6. Starting the line trimmer

1. Connect the extension cord to a power supply.
2. To switch ON the line trimmer press the On/Off
3. To switch OFF simply release the On/Off switch (a).

7. Trimming grass and weeds

Your line trimmer will work at its best if you observe the
following instructions:
• Never use the line trimmer without its safety devices.
• Do not cut grass when it is wet. The best results are
• To switch ON your line trimmer, press the On/Off
• To switch OFF your line trimmer, let go of the On/Off
• Do not move the line trimmer against the grass until
• For the correct cutting action, swing the line trimmer
• Make several passes to cut long grass shorter step by
• Keep the line trimmer away from hard objects in order
GB-6
WARNING! Before marking this change, make sure
that line trimmer is switched off and unplugged.
ing, then rotate shaft to the edging position.
clicks into position and you hear the "click" sound.
though the square hole under the grip of the On/
Off switch (a).
ensure it is pulled firmly enough to prevent it from
coming loose whilst operating the trimmer.
mer cord plug
switch (a).
WARNING! The line trimmer runs for a few sec-
onds after it has been switched off. Let the motor
come to a complete standstill before setting
the tool down.
WARNING! Make sure that the work atrea is free
of rocks, debris,lines and other foreign objects.
achieved on dry grass.
switch (a).
switch (a).
the switch is pressed, i.e. wait until the line trimmer is
running before placing in grass.
from side to side as you walk forward, holding it at an
angle of approx.30°as you do so.
step from the top (Fig.11).
to avoid unnecessary line wear
