English

Package Contents

ImageMate 12-in-1 Reader/Writer with docking station (storage media not included)
Installation CD with Windows 98SE driver, button application and User Guide
Extra USB travel cable
Quick Start Guide
Before connecting the ImageMate 12-in-1 Reader/Writer to your computer, you may need to install the device driver.
You can skip this section if your operating system is Windows XP, ME, 2000, Vista (and proceed to Installing
the Button Application), Mac OS 9.2+ or Mac OS 10.1.2+ (and proceed to Connecting).
Install the Windows 98SE and Windows 2000 driver
(for systems with Windows 2000 and with SP1 or SP2 installed)
1. Insert the CD included with the ImageMate 12-in-1 Reader/Writer into the CD-ROM of your computer.
2. Left-click on the START menu and open the RUN menu. Click BROWSE to locate the drive letter of your
CD-ROM.
3. Select the setup.exe file and click OK. Follow the on-screen directions.
Install the Macintosh 9.2.X driver
1. Install the CD included with the ImageMate 12-in-1 Reader/Writer into the CD-ROM of your computer.
2. Double-click the CD-ROM icon on the desktop and then run the USB Reader Installer application for your
Macintosh operating system. The Read Me file opens first.
3. Click Continue.
4. In the Installer Dialog, select USB Reader Installer in the drop-down menu and then click Install to install the
device driver.
5. Follow the on-screen directions.
Installing the Button Application
(only for Windows)
1. Insert the CD included with the ImageMate 12-in-1 Reader/Writer device into the CD-ROM of your computer.
2. Left-click on the START menu and open the RUN menu. Click BROWSE to locate the drive letter of your
CD-ROM.
3. Select the \Button Application\setup.exe file and click OK. Follow the on-screen directions.
Installing
2 2
There are two ways to connect your ImageMate 12-in-1 Reader/Writer to your computer:
1. I nsert the ImageMate 12-in-1 Reader/Writer into the Docking Station. Connect the Docking Station cable to
your computer.
2. Use the extra Travel USB cable to connect your ImageMate 12-in-1 Reader/Writer to a computer directly (the
Docking Station is not required in this case)
When the ImageMate 12-in-1 Reader/Writer is connected for the first time, your computer may display a message that
the device is being installed (may vary slightly depending on your operating system).
Windows Disk Icons
When you connect the ImageMate 12-in-1 Reader/Writer on a Windows operating system four removable disk icons
representing the media slots show in My Computer with newly assigned drive letters.
Macintosh Disk Icons
When you connect the ImageMate 12-in-1 Reader/Writer on a Macintosh operating system, removable disk icons
labeled 'no name' representing the media slots show on desktop when media is inserted.
The ImageMate 12-in-1 Reader/Writer has four media slots. Each slot can be used for two or more types of media.
When you install the ImageMate 12-in-1 Reader/Writer, you will see four new removable drives appear.
Inserting Media
To install media into one of the Reader/Writer's slots,
insert the connector end of the card/stick.
Do not force the media into the slot.
For SmartMedia/xD and xD type M & H, insert with gold
plated side facing the SanDisk logo on the side of the
ImageMate 12-in-1 Reader/Writer.
Connecting
–or–
Using
SD(HC)
Memory Stick
miniSD(HC)
Memory Stick PRO
MultiMediaCard
➂ ➃ Memory Stick Duo
MMCplus
Memory Stick PRO Duo
MMCmobile
Memory Stick PRO-HG Duo
RS-MMC
RS-MMC Dual Voltage
SmartMedia
CompactFlash I
➁ xD
➀
CompactFlash II
xD Type M & H
3
