HEADZONE ® PRO XT – QUICK INSTALLATION GUIDE
Rear view
16 17
Head tracker connector
16
Connector for "Headzone
Com input
17
Balanced XLR mono input for line level signals (6 dBu nominal, 15 dBu clip). This additional signal can be routed
to the virtual L, R, LS and RS loudspeakers. The volume of the Com channel can be set with the Com Volume
control on the front of the device.
4
Analogue inputs
18
6 balanced analogue inputs for Line level (6 dBu nominal, 15 dBU clip) via 25-pin Sub D socket
AES/EBU In
19
The AES/EBU connector provides 6 digital inputs according to the AES3 or EBU Tech-3250E standard, which are
three XLR sockets each for two channels supporting sample rates up to 192 kHz.
Digital audio input (IEEE 1394)
20
The digital IEEE 1394 (Firewire) connector provides 6 digital audio inputs with a sample rate of up to 96 kHz.
Furthermore, the Firewire connector is used for exchanging configuration data between the Headzone
hardware and Headzone
Headzone ® utilizes a standard 6-pin Firewire connector and supports the IEEE 1394-A standard. Use an
appropriate adapter cable to connect a 4-pin Firewire port (common on notebooks) or an 8-pin Firewire port
(IEEE 1394-B Standard).
Note:
- The labelling of the Firewire connection can differ, e.g. it can also be "iLink" or "1394" etc.
- Headzone ® unterstützt nicht die Stromversorgung über den Firewire 1394-Bus.
Power connector for 100 - 240 V, 50 Hz or 60 Hz.
21
18
Rail" (head tracker receiver), balanced.
®
® software control panel.
- 14 -
19 20 21
®
