Note:
Although the surround processing is completely disabled in the "Bypass" mode, the playback volume will still be
influenced by the "Distance" and "Ambience" parameters. This is because switching between processing and
bypass could otherwise lead to a dramatic increase of volume and therefore damage your hearing. Locking the
playback volume to the "Distance" and "Ambience" parameters will always provide a convenient volume
balance between bypass and processing mode.
Bypass Status LED
8
Off = Headzone ® processing activated
Red = Bypass mode
Input Select button
9
By pressing the "Input Select" button you can switch between the analogue Sub-D
1394 and AES/EBU
20
Input Select LEDs
10
Analog LED green
Analog LED red
FW LED green
FW LED red
AES/EBU LED green
AES/EBU LED red
Note:
The appropriate "Input Select" LED will light up red when less than 6 dB of headroom is left for at least one
audio input. Separate "Peak" LEDs for every audio channel (except Com channel) are displayed in the Headzone
software control panel.
Master volume control
11
Master control for the headphone volume. When working with the Headzone
volume control to minimum and then slightly increase the volume to a decent value.
EarPatron noise level LEDs
12
Seven LEDs display the achieved EarPatron noise level in per cent.
EarPatron noise level reset button
13
With this button you can reset the EarPatron noise level to 0%.
Limiter LED
14
Limiter LED green – Limiter activated
Limiter LED red – Limiter actively limits the output signal
Headphone sockets
15
Headzone ® PRO XT provides two 1/4" (6.35 mm) jack sockets to connect up to two headphones. As the head
tracker does not operate properly when two headphones are simultaneously used, Headzone
turns off the head tracker when two headphones are connected.
Note:
When connecting two headphones, the impedance changes from the device perspective. For calculating the
EarPatron noise level, Headzone
headphones are connected to the device, the displayed noise level is useless, as it does not represent the whole
impedance of the system.
audio inputs.
19
- Analogue inputs are activated
- Analogue inputs are close to clipping
- Firewire inputs are activated
- Firewire inputs are close to clipping
- AES/EBU inputs are activated
- AES/EBU inputs are close to clipping
® assumes that two identical headphones are connected. If two different
®
- 13 -
, the digital Firewire IEEE
18
system, always set the master
® automatically
®
