ORANGE diode
GREEN diode
After thermostat instalation, to access the adjusting elements, remove the screw
and lift the transparent cover of the controls. It is then possible to set the controls.
Turn the control knob
a) ON - the thermostat is still closed regardless of temperature,
b) OFF - the thermostat is always switched off regardless of temperature,
c) position 30 °C to 80 °C - the thermostat switches on the output when the set
temperature is exceeded and switches off when the temperature fall by set
hysteresis with 2
Anti-scale protection - if the pump is inactive for more than 24 hours, it will be
Power supply
Power consumption
Type of regulation
Range of regulation
Ambient temperature
Degree of protection
Protection class
Output type
Max. load (resistive)
Dimension
In case of warranty or post-warrant service, send the
product to the manufacturer's address together with a
copy of the purchase receipt.
DOIDE INDICATION
RED diode
RE
ERR
PWR
to the desired position:
1
.
switched on for about 15 seconds.
Technical parameters
Pb Pb
LEAD FREE
v souladu s RoHS
LIT = RELAY indication
BLINKING = sensing sensor error
LIT = power indication
SETTINGS
230 V / 50Hz
< 1W
hysteresis ( 2 °C až 20 °C)
+30 °C až +80 °C
0 °C až +40 °C
IP20
II
potential-free
relay (
10 A/ 250 V AC
130x44x35
MADE IN CZECH REPUBLIC
www.elbock.cz
9
contacts)
ELEKTROBOCK CZ s.r.o.
Blanenská 1763
Kuřim 664 34
CZ Tel./fax: +420 541 230 216
Technická podpora (do 14h)
Mobil: +420 724 001 633
+420 725 027 685
C
