The electronic thermostat
depending on the set temperature and hysteresis. The advantage is the
adjustable hysteresis (2 °C to 20 °C), easy adjustment of the control
temperature and easy installation directly on the surface of the tube. In
addition, it contains anti-scale protection. Its mounting is carried out by a
tension spring. Controls and connection terminals are secured against
unwanted manipulation with the lock screw.
- a screw for access to the adjusting
A
elements
B
- a screw for access to the terminal blocks
- safety cover of terminal
C
- output terminals (potential-free)
D
Imax = 10 A/ 250 V AC
! Warning:
The installation can only be done by a properly qualified person! Disconnect power
Upozornenie:
supply before installation!
Installation:
1) Place the thermostat to the desired location on the tube (
measuring part
2) Using a spring, secure the thermostat on the spot (
3) Loosen the screw
4) Connect the wires according to
5) Replace the cover and secure it with the screw.
Recommendation: When using a wire guide, use the sockets (
i
For a more accurate temperature measurement, it is recommended to use a
heat conducting paste and to remove the dirt from contact surface.

Electronic pipe thermostat

with ON/OFF function
Instructions for use
PT02

DESCRIPTION AND INSTALLATION

of the thermostat abut on its surface.
F
and remove the bottom bezel
B
I4
is used to switch circulating pumps
- power terminals (~ 230 V/ AC)
E
- sensing element
F
-
1
-
2
I2
I5
(see detail ).
8
control temperature setting
(30 °C to 80 °C)
hysteresis setting
(2 °C až 20 °C)
I2
) so that the
).
by sliding it upwards.
C
I6
)
