3.8 Measuring Capacitance
To avoid electrical shock and damage to the meter when
measuring capacitance in a circuit, make sure the power to the
circuit is turned off and all capacitors are discharged.
Only Autorange is available in this mode.
1. Turn the rotary switch to
make sure power is disconnected from the circuit to
be measured.
2. Connect the red test lead to the + terminal and the black test lead to the COM
terminal.
3. Press the yellow button three times.
4. Touch the probes to the capacitor leads.
5. After allowing reading to stabilize, read the capacitance value on the display.
In the capacitance range 100mF the measure can be long and exceed 15s.
29
