Use Instructions; Care And Maintenance - Be Cool Funky Gebrauchsanweisung

GB
TO UNFOLD AND ASSEMBLE
1
UNFOLD FRAME
Release the folding lock first,to grasp both han-
dles, lift up quickly to open frame and press
down handles until hear "Clicks"
2 TO ASSEMBLY REAR WHEELS
Insert rear wheel pegs into plastic houses until
hear "clicks".
To disassemble: Press down the latch on plastic
house and pull rear wheels set out.
3
TO ASSEMBLE FRONT WHEELS
Insert front wheel set peg into the plastic base
until hear a "Click".
To disassemble: Press in the button on the plas-
tic base and pull the wheel set out.
4 TO ASSEMBLE THE CANOPY
Align the holes on the canopy fixture with the
fixing rivets head on the handles. Press the fix-
ture onto the handles .Snap on the buttons as
Figure C shown;

USE INSTRUCTIONS

5
TO USE BRAKING SYSTEM
Press down rear wheel parking brake lever,check
the brake is on by pushing the stroller.
Press it down again to release the brake.
6 TO ADJUST CANOPY
Pull forward or press back ward the canopy wire
to open or close canopy
7
TO USE FRONT SWIVEL LOCK
Press down on swivel lock lever to swivel;Pull
back the swivel
lock lever and fix it into the base notch,the whe-
el can only move steadily.
8 TO ADJUST BACKREST
To raise seat,hold the adjusting buckle(a)
tightly,grasp the plastic ring fixed to the end of
the adjusting webbing and pull up.
To lower seat,press down the gray button and
pull back the seat.
Warning:Do not adjust seat while child is in stro-
ller.
IM 1369 FUNKY.indd 11
9 TO USE RESTRAINT SYSTEM
To unlock buckle,press in on center button and
pull harness out from each side.To buckle, push
each side of harness back into buckle until each
clicks in place.
10 TO ADJUST WAIST STRAP LENGTH
To shorten,pull bottom loop(2) down,then pull
on strap end(1). To lengthen,pull out top loop(3),
Then pull out on buckle.
11
TO FOLD THE STROLLER
Press down the second lock button,pull up the
fold latches on handles and push forward the
handles at the same time.Press them down to
fold the frame
12 BRAKE SYSTEM ADJUST INSTRUCTION
Caution: Always check and adjust the brake
cable to make both brakes work corrcectly .Do
NOT overstep brake pedal; Follow up below ins-
tructions to adjust brake system:
1.Screw the adjust nut to right side to tight
brake pedals;
2.Screw the adjust nut to left side to loose the
brake pedals;
3.After screwing the adjust nut into correct po-
sition, fix the fixing nut to secure adjust nut.

CARE AND MAINTENANCE

• Always store in a clean and dry place.
• Clean the frame by wiping with a damp
cloth.
• Do not use abrasives, bleach or strong de-
tergents.
• Spot clean fabrics with warm water and
mild soap.
• Ensure fabric is dry before storing.
• Occasionally clean and lubricate wheels
and axles with a light lubricating oil.
• Regularly check for loose parts and tighten
when required.
• Damaged or broken parts should be re-
placed.
