7.3 Technical data for stand

Stand Base Number of feet
Foot length
Castor diameter
Stand post Length
Telescoping
Power cord connec-
tion
Light arm + Assembly
Light body

7.4 Electrical installation information

The KaWe examination light is exposed to a current peak when it is
switched on and is therefore equipped with a power adapter.
Warning! This light is a Protection Class II device. To avoid
the risk of electric shock, this unit must be connected to a
grounded electrical outlet.

7.5 Weights

Examination light
MASTERLIGHT® Examination lamp LED, 7W
* with 5-foot base

7.6 Environmental conditions

Temperature
Relative humidity
Air pressure
* for higher temperatures please contact us
Temperature
Relative humidity
Air pressure
5
310 mm
approx. 50 mm
1.400 mm
no
yes
• Light arm with light body
preassembled
• Light arm on floor stand
Weight
5.0 kg*
Operation
Min. Max.
+10° C +30° C*
30 % 75 %
700 hPa 1060 hPa
Transport/storage
Min. Max.
–10° C +50° C
20 % 90 %
700 hPa 1060 hPa
Instructions on the packaging
Temperature range Humidity during
during transport and transport and
storage storage
+50° C
–10° C
20% - 90%

7.7 Important information

If multiple KaWe examination lights are used at once, the total
irradiance may exceed 1,000 W/m² due to superposition of the lumi-
nous fields. As a result, there is a risk that the illuminated field may
become very hot. The superposition of the luminous fields of multiple
KaWe examination lights may cause the limit values for UV radiation
(<400 nm) of 10 W/m² to be exceeded.
The report on the factory test for electrical safety can
be obtained upon request. The only requirement is the serial
number of the KaWe examination light for which the proto-
col is desired. If other KaWe examination lights or other
pieces of equipment are connected together during installa-
tion, section 16 of EN 60601-1:2013 applies and if necessary,
the compliance with the requirements is to be verified.
Before initial operation, the installation must be inspected
in accordance with EN 62353.

8. CE-LABEL

This KaWe examination light complies with guidelines 93/42/
EWG (guidelines for medical products from the council of the Europe-
an communities). The applicable standard is EN 60601-2-41. The
company KaWe GmbH + Co. KG is certified according to DIN EN ISO
13485:2012 + AC:2012. .

9. DISPOSAL

At the end of the product's life, the components of the KaWe
examination light are to be disposed of properly. Ensure that the mate-
rials are sorted carefully according to type. The electrical circuit boards
are to be disposed of at an appropriate recycling centre. The lamp
housing and the rest of the components of the KaWe examination light
should be disposed of according to their type of material.
Air pressure during
transport and
storage
RH P
700hPa - 1060hPa
