If the machine should fall into the substance to
be stirred, immediately pull out the mains plug
and have the machine overhauled by the cus-
tomer service.
Pay attention to the reaction torque of the
machine.
Always switch off the machine and allow to
come to a stop before placing it down.
Do not leave the tool key inserted.

Intended Use

The machine is intended for stirring powder-type
building materials such as mortar, plaster, cement,
and solvent-free paints, varnish and similar sub-
stances.
The user alone is responsible for any liabilities
caused by usage other than intended.
Starting
Ensure that the voltage of the power supply matches
the information on the type plate of the power tool.
Tools with a rating of 230 V can also be connected
to a 220 V/240 V supply.
Improper use may damage the machine.
Observe the following instructions:
- Use only tools up to the specified stirror diame-
ters.
- Load the instrument in such a way that the speed
would not drop considerably or that it would
stop.
Connecting the mains cable module
(Plug it - MXP 1000 EQ)
The machine is equipped with a quick-change
mains cable module (12). By disconnecting the
mains cable and the machine, both can be trans-
ported easier.
Insert the mains cable module (12) into the socket
(10) of the machine and secure by turning the sleeve
(11) in clockwise direction.
To undo the connection, turn the sleeve (11) in
counterclockwise direction and pull the mains cable
module (12) from the socket (10).
Use the mains cable module only for PRO-
TOOL power tools. Do not attempt to oper-
ate other machines with it.
Auxiliary handle
For safety reasons, always use the auxiliary handle
(1).
Assembling the auxiliary handle
(MXP 1000 EQ)
Assemble the auxiliary handle as shown in Fig..
When assembling the auxiliary handle, tighten the
four screws using a hex key (size 5 mm).
Use only the fastening material included in the
delivery.
Switching on and off
Press the On/Off switch (2) to switch on the
machine. Release again to switch off.
Continuous use
Switching on: Press the On/Off switch (2), hold and
retain with the lock-on button (3).
Switching off: Press and release the On/Off
switch (2).
Speed Control
Lightly pressing the On/Off switch (2) results in a
low rotational speed, allowing a controlled soft
start.
Further pressure on the switch results in an increase
in speed.
Electronic speed pre-selection
The required speed can be pre-selected with the
speed selector thumbwheel (4) (also possible during
operation).
The required speed depends on the material being
machined and can be determined by trial.
When putting a high load on the machine, always
set the speed selector thumbwheel (4) to the maxi-
mum speed.
After long periods at low operating speed, run the
drill at high speed and without load for approx. 3
minutes, in order to cool the machine down.
Clamping the stirrer tools
Screw the M 14 x 2 end piece of the stirrer tools as
far as possible into the tool holder (6) and tighten
with the open-end wrench (8) (size 22 mm) from the
accessories.
Dismantling the stirrer tools
Attach the open-end spanner (8) (size 22 mm) onto
the hexagon of the stirrer end piece and unscrew the
stirrer tool from the spindle by turning in counter-
clockwise direction.
