If the stirrer tool is tight, attach a second open-end
spanner (MXP 1000 EQ - size 22 mm/ MXP 800 -
size 17 mm) onto the wrench flats (7) and loosen the
stirrer tool by counter-turning with both open-end
wrenches.
Operational Tips
Do not mix explosive substances (e. g. easily
inflammable solvents) and materials with a com-
bustion point below 21 °C. Observe the process-
ing instructions of the manufacturer.
The choice of stirrer (9) depends on the nature of
the substance to be stirred. For substances with low
viscosity, such as for example, dispersion paint,
varnish, cement, sealing compound or cement
grout, use a stirror with a left twist. For substances
with high viscosity, such as for example, ready-
mixed plaster, concrete, cement, screed, putty and
epoxy resin, use a stirrer with a right twist.
Move the machine up and down while stirring.
Clean the stirrer after use.
Storage
The unit should be stored in a dry place where it is
protected against freezing.
Environmental Protection
Do not open worn out machines and return to the
collection facilities provided for recycling.

Maintenance

Periodically clean the venting slots ( 5) on the
motor housing.
When the carbon brushes are worn out, the
machine switches itself off. The machine must
then be sent to customer service for maintenance
(see enclosed sheet).
After approx. 100 hours of operation, check the
motor brushes and replace if necessary. Clean
the motor housing.
After approx. 200 hours of operation, renew the
grease filling in the gearbox.
To verify that the double insulation is intact,
the machine must be subjected to a safety test
afterwards. Therefore, these maintenance
tasks are to be performed only by a profes-
sional electro-workshop.
10
Service
See enclosed sheet.
Guarantee
We guarantee PROTOOL appliances in accordance
with statutory/country-specific regulations (proof
of purchase by invoice or delivery note).
Damage attributable to normal wear and tear, over-
load or improper handling will be excluded from
the guarantee. Also not included in the guarantee
claims are the costs for maintenance work and the
replacement of carbon brushes.
In case of complaints please send the machine,
undismantled, to your dealer or the Service Center
for electrical power tools.
Declaration of Conformity
We declare under our sole responsibility that this
product is in conformity with the following stand-
ards or standardization documents: EN 50 144-1,
EN 55 014-1, EN 55 014-2, EN 61 000-3-2,
EN 61 000-3-3 according to the provision of the
regulations 73/23/EEC, 89/336/EEC, 98/37/EC.
Dr. Josef Lorenz
NAREX âeská Lípa a.s.
Chelãického 1932
47037 âeská Lípa
Subject to change
