Display Designation / description
"choice"
"on" function on
"oFF" function off
_LAn_ Language:
To choose the language displayed.
"GEr" German
"EnGL" English
_CtrL
For service only

9. Input Mode

Incremental measurement function
Press keys to activate incremental measure-
ment function.
• The display is zeroed.
• Decimal point is blinking.
• Leave incremental measurement function press
keys . The absolute measuring value is dis-
played again.

Appendix: Parameter list

(in English language, parameter _SPr_ = "E")
Display Designation / range
_tYP_
operating mode: Poti, U_10, 0_20, 4_20
_dP_
decimal point: 0. , 0.0 ,0.00 , 0.000
CAL_L
lower alignment value: 0000 ... +/-9999
CAL_U
upper alignment value: 0000 ... +/-9999
_uPL_ lower limiting value of swiched outputs:
0000 ... +/-9999
_LoL_
upper limiting value of swiched outputs:
0000 ... +/-9999
L_tYP
interpretation of limit value: AbS, rEL
P_S_
delay of key in seconds:
1, 3, 5, 10, 20, 30
_F_rEL
incremental measurement enable: on, oFF
_LAn_
language: GEr, EnGL
SIKO GmbH
Werk / Factory:
Weihermattenweg 2
79256 Buchenbach-Unteribental
Postanschrift / Postal address:
Postfach 1106
79195 Kirchzarten
8 MA50
Precondition: Menu point 'Incremental measure-
ment enable' (F_rEL) in programming mode must
be programmed to "on", but unit must not be left
in programming mode (see chapter 7‚ 'To leave
programming mode').
10. Trouble Shooting
Message: Error
Description: Signal current of encoder in the
"4...20" operating mode is below 3mA.
Action: -check line between encoder and measu-
rement display for interruptions.
-check signal encoder.
Message: Decimal point is blinking
Description: Device cannot be calibrated to the
set upper or lower alignment value any more.
Action: Device is in the incremental mode. Actu-
ate the
the absolute measure.
Description: Display does not show the desired
values.
Action: Align display (see chapter 7.1).
Telefon/Phone
Telefax/Fax
E-Mail
Internet
Service
Datum 13.07.2010
key to enforce return of the display to
Factory Your program-
setup ming I
Poti
0.0
0.0
100.0
0.0
0.0
AbS
5
oFF
GEr
+49 7661 394-0
+49 7661 394-388
info@siko.de
www.siko.de
support@siko.de
Art.Nr. 80955
Your program-
ming II
Änd. Stand 239/10
