one long and three short signal tones sound).
4. Press the Monitor key and a signal tone sounds. (that is, when pilot tone 25 is set on the
channel, two short signal tones and after a short pause, five additional tones will sound).
5. Turn the unit off when the check is complete.
Confirming the signal tone
Number Signal tone
0 1 second tone
1 .
2 ..
3 ...
4 ....
Default values of the channels
Channel number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16 (S)

8.5 Accessories

9.5.1 Headset
Only the microphone-loudspeaker combination Ex-HS 01 may be used.
8.5.2 Charger
The battery must only be charged outside of the Ex-area with the designated charger
LS PMR 1000 and the corresponding power supply unit PS PMR 1000.

9. Charging the battery module

9.1 General Information

Turn the radio unit off before charging the battery module. Using the device while charging
can result in charging problems.
Use only the approved charger LS PMR 1000 and the corresponding power supply unit
32
Number
5
6
7
8
9
Default frequency
1 (446,00625)
2 (446,01875)
3 (446,03125)
4 (446,04375)
5 (446,05625)
6 (446,06875)
7 (446,08125)
8 (446,09375)
1 (446,00625)
1 (446,00625)
2 (446,01875)
2 (446,01875)
3 (446,03125)
3 (446,03125)
4 (446,04375)
Search run
Signal tone
.....
-.
-..
- ...
-....
Default CTCSS/DCS
0 (OFF)
0 (OFF)
0 (OFF)
0 (OFF)
0 (OFF)
0 (OFF)
0 (OFF)
0 (OFF)
1 (67,0 Hz)
39 (D023)
1 (67,0 Hz)
39 (D023)
1 (67,0 Hz)
39 (D023)
1 (67,0 Hz)
