Ecom Ex-PMR 1000 Bedienungsanleitung Seite 25

8. Technical data
Ambient temperature Ta:
Storage temperature:
Charging temperature:
Power supply:
Period of operation:
Charging time:
Dimensions:
Frequency range:
Sensitivity:
Channels:
Channel grid:
Max. Transmission power:
NF – power output:
Weight:
IP rating:
CE designation:
Channel frequency table
Channel Frequency
1 446,00625
2 446,01875
3 446,03125
4 446,04375
9. Functional description / operating information
Please take the time to carefully read through this owner's manual to ensure that you are
familiar with all of the functions of your Ex-PMR 1000 and know how to use them. For you
own safety and information please read through the information on the following pages.
9.1 Display and control elements, connections
24
-20°C ..... +50°C
-20°C ..... +60°C
0°C ..... +40°C
Ex-battery pack Ex-AM PMR 1000
approx. 12 hours (90% standby, 5%TX, 5%RX)
approx. 4 hours
126 x 64 x 42 mm
446.00625 – 446.09375 MHz
approx. 0.30 μV at 12 dB SINAD
8
12.5 kHz
0.5W ERP
max. 0.5 W
approx. 450g (including battery pack)
IP 54
0102
0678
(MHz) Channel Frequency (MHz)
5 446,05625
6 446,06875
7 446,08125
8 446,09375
