Ecom Ex-PMR 1000 Bedienungsanleitung Seite 31

No CTCSS/DCS
0 OFF
1 67,0 Hz
2 71,9 Hz
3 74,4 Hz
4 77,0 Hz
5 79,7 Hz
6 82,5 Hz
7 85,4 Hz
8 88,5 Hz
9 91,5 Hz
10 94,8 Hz
11 97,4 Hz
12 100,0 Hz
13 103,5 Hz
14 107,2 Hz
15 110,9 Hz
16 114,8 Hz
17 118,8 Hz
18 123,0 Hz
19 127,3 Hz
20 131,8 Hz
21 136,5 Hz
22 141,3 Hz
23 146,2 Hz
24 151,4 Hz
1. Turn the device on while holding down PTT and the monitor key at the same time.
Only release PTT and the monitor key when the LED display illuminates in orange.
2. Press the monitor key until the LED display changes from orange to green and a signal
tone sounds, which means that the radio unit is changing to the CTCSS/DCS set mode.
3. Select the desired channel storage space using the channel switch.
4. Select the "tens" digit of the signal number between 0-9 by pressing PTT. Each time you
press it, the signal number changes and is accompanied by a signal tone.
5. The respective signal tone of the selected number sounds after 2 seconds.
6. By pressing PTT, select the unit of the signal number from 10 different numbers 0-9.
Each time you press it, the signal number changes and is accompanied by a signal tone.
30
No CTCSS/DCS
25 156,7 Hz
26 162,2 Hz
27 167,9 Hz
28 173,8 Hz
29 179,9 Hz
30 186,2 Hz
31 192,8 Hz
32 203,5 Hz
33 210,7 Hz
34 218,1 Hz
35 225,7 Hz
36 233,6 Hz
37 241,8 Hz
38 250,3 Hz
39 D023
40 D025
41 D026
42 D031
43 D032
44 D043
45 D047
46 D051
47 D054
48 D065
49 D071
No CTCSS/DCS
50 D072
51 D073
52 D074
53 D114
54 D115
55 D116
56 D125
57 D131
58 D132
59 D134
60 D143
61 D152
62 D155
63 D156
64 D162
65 D165
66 D172
67 D174
68 D205
69 D223
70 D226
71 D243
72 D244
73 D245
74 D251
No CTCSS/DCS
75 D261
76 D263
77 D265
78 D271
79 D306
80 D311
81 D315
82 D331
83 D343
84 D346
85 D351
86 D364
87 D365
88 D371
89 D411
90 D412
91 D413
92 D423
93 D431
94 D432
95 D445
96 D464
97 D664
98 D723
99 D754
