Operation
Press and hold
PTT for 2 seconds
Press PTT one time
Press PTT two times
Press PTT three times
Press PTT four times
Press PTT five times
Press PTT six times
Press PTT seven times
Press PTT eight times
Please observe:
Select channel number "0" when not selecting any channel. To do so, press PTT for about 2
seconds until a 1-second long signal tone sounds.
If PTT is pressed more often than 8 times, a signal tone sounds and no value is selected.
5. The respective signal tone of the selected number sounds after 2 seconds.
6. Press the monitor key to end this setting. The red LED display flashes two times.
7. Press the monitor key again to confirm the signal tone of the desired number.
8. Program another channel as described in steps 3 through 7 above.
Example: Changing a channel storage space (11) to channel number 8
1. Select channel storage space 11 in the set mode.
2. Press PTT 8 times to select 8 as the channel number. Each time you press it,
a signal tone will sound.
3. After 2 seconds, one long and three short signal tones sound, to confirm your
selection of channel number 8.
4. Press the monitor key to complete the setting. The red LED display flashes two times.
5. Press the monitor key again. One long and three short signal tones confirm that channel
number 8 has been selected.
8.4.3.2 Pilot tones
Please observe:
After programming is complete, switch the unit off and back on again, so that it is back in
the operating mode.
All of the CTCSS/DCS pilot tones are listed in the following table.
After confirmation of a signal number > 10, a short trace occurs between the tens and the
units.
Channel number
0
1
2
3
4
5
6
7
8
Signal tone
1 second tone
.
..
...
....
.....
-.
-..
-...
