PM5 Menu Map

Sample Display

Total elapsed time.
Total meters.
Average pace (in time) per 500m
(indoor rower/SkiErg) or per
1000m (BikeErg). This is the
average for your entire workout.
Split meters. The number of
meters in a given distance or
time. In Just Row/Just Ski/Just
Bike, splits are five minutes long.
UNITS
Push to change units between Meters (m), Pace,
Watts and Calories (Cal).

PM5 Views

Back View of PM5
Battery cover
Reset button
More Information
Using a Heart Rate Monitor:
The PM5 will receive and display heart rate
data directly from a Bluetooth, Suunto™,
Garmin ® or ANT+ ™ HR chest belt. See More
Options for set up.
WARNING!
Heart rate monitoring systems may be inaccurate. Over-exercising
may result in serious injury or death. If you feel faint, stop exercising immediately.
8
(Visit concept2.com/PM5 for more information.)
Memory
USB flash drive port
Race system jacks (2)
USB-B
USB cable (optional)
to computer or
phone/tablet
Strokes per minute (s/m) for the indoor
rower/SkiErg. Revolutions per minute (rpm)
for the BikeErg.
Pace (time/500m for indoor rowers and SkiErg;
time/1000m for BikeErg). A faster pace is indicated
by a shorter time to cover the distance.
Heart rate
(Optional. Requires additional chest belt.)
Projected meters in 30 minutes if the current
average pace is maintained.
MENU
Push to power up the PM, display the previous
menu or save workout results.
DISPLAY
Push to change display between All Data, Force Curve,
Paceboat/Pace Skier/PaceRider, Bar Chart, and Large Print.
D
Bottom View of PM5
Cleaning the PM
Use a cloth lightly dampened with water
only. Do not spray with a cleaner or store
outdoors.
Troubleshooting
Visit concept2.com/pm5.
Remove D Cell (LR20)
batteries from the PM5
if monitor will not be
used for a period of four
months or more.
D
Sensor cable
to flywheel
