Congratulations on your purchase of the new SWIFT S-1 ARF.
The SWIFT S-1 ARF is a high-quality semi-scale aerobatic glider with a dynamic flight envelope.
It can be flown within in a broad speed range and also in aerobatics. There a various ways of const-
ructing the model, depending on your preferences.
Therefore the solutions stated in this manual should only be considered as recommendations.
This ARF version (almost ready to fly) requires modeling experience and basic technical knowledge
in construction.
Thus there are different ways to achieve a model with good flight skills.
This is why most alternatives are in fact explained in the manual but not necessary shown in the
pictures.
PLEASE READ THIS MANUAL CAREFULLY BEFORE YOU START ASSEMBLING THE MODEL!
Span
Length
Weight (dry)
Wing area
Airfoil
ESC Doppelstromversorgung
Servos HR: 1x Savöx 1256 oder Hitec HS-645MG
SR: 1x Savöx 1256 oder Hitec HS-645MG
QR: 2x Savöx 1250 oder Savöx 1260
WK: 2x Savöx 1250 oder Savöx 1260
Servo cables 2x 80cm + 2x 30cm
Battery 2x 2S LiXX 1400mAh
Optional Schleppkupplung, Fahrwerk
TX min. 5 Channels
RX min. 7 Channels
Glues 5min epoxy resin, Loctite
UHU Por, Velcro tape
INTRODUCTION

SPECIFICATIONS

3330 mm
1140 mm
3850 g
73,2 dm²
NACA mod.
NEEDED ACCESSORIES
