Technical specifications

Channels
Frequency range
Channel spacing
Power supply
Temperature
Dimensions (w/o batteries)
Weight (w/o batteries)
Duty cycle
Category
Transmitter
Output power
Modulation
Spurious rejection
Receiver
Sensitivity @ 12dB Sinad
Adjacent channel rejection
Audio output power
Jack for ext.mike and recharge
Jack for ext. speaker
Maximum transmission time
in an hour
Specifications are subject to change without notice.
WARNING: Direct plug-in ac/dc power supply must be used for disconnecting the
transceiver from the mains; the desktop charger must be positioned close to the
unit and easily accessible.
Midland G7 Pro user's manual
1~8 PMR, 1~69 LPD
446.00625 ÷ 446.09375MHz
(PMR)
433.075 ÷ 434.775MHz (LPD)
12.5 KHz (PMR); 25 KHz (LPD)
6+/- 10% Vdc
from -20° to +55°C
58 (L)x 122 (H)x34 (D) mm
123gr
TX 5%, RX 5%, stand-by 90%
B
10 or 500 mW (Selectable)
FM
within European legal terms
0,35µV
70dB
300mW @ 10% THD
stereo 2,5 mm
mono 3.5 mm
6 minutes, equivalent
to a duty cycle of 10%
