9. POWER button (press and hold to turn on/off)
Note: if the memory card has been inserted beforehand, the device will automatically
start recording)
10. MENU
11. MODE button (press to change between modes: camera/photo/playback)
12. UP button (press to go to previous option / change between display modes)
13. DOWN button (press to go to next option)
14. OK button (confirm / start/stop recording/take photo)
Rearview camera and sensor
1. Rearview camera
2. Parking sensor
MOuNtiNg
Sensor and rear view camera installation
Prior to installation, select and mark suitable location. If possible, and tape off the
area to be drilled with masking tape in order to protect the surroundings. The sensor
and camera (1) should be located in a place that provides:
1. proper field of view, with no parts of the vehicle within its sensing area which in
turn could disturb their operation.
2. the sensor and camera axis should be parallel to the surface of the road surface
3. before drilling the holes in vehicle's body, make sure to select location in which
you will not damage any electrical cables, brake system, fuel tank etc.
4. before drilling a hole, determine the best way to run the cables through the
vehicle. Ensure the cables does not interfere any safety equipment nor reduce
safety of the vehicle.
DOUBLE CHECK BEFORE YOU DRILL! Look out for cables, sensors, lines,
anything that could get damaged.
5. After drilling, remove any burs or sharp edges so you do not damage the cable
User's manual
①
②
EN
13
