LAVAZZA Espresso Point EP2302 Gebrauchsanweisung Seite 16

GB
Make the water mains connection with the machine
switched off and separated from the power mains.
After having positioned the machine connect the water
mains to the rear 1/8 GAS union (fig. 1).
It is advisable to make the connection with an armoured
pipe fitted with a filter and/or a bleeder valve.
It is not necessary to access the tank.
For standard machines: remove the access lid on the right of the tank using the key
supplied (Figure 2); release the central lid (Figure 3), remove the tank (Figure 4) and fill
it with drinking water (preferably with a low lime content).
In all cases: power the machine by connecting its lead with the electrical outlet (Figure 5).
Move the switch on the back of the machine to position "I" (Figure 6).
Fig. 2
Fig. 5
Fig. 3
Fig. 6
14
Fig. 1
Fig. 4
R R e e a a r r c c o o n n n n e e c c t t i i o o n n s s o o f f
E E s s p p r r e e s s s s o o P P o o i i n n t t
