AKG MicroMic C 417III Bedienungshinweise Seite 18

2 Interfacing
MPA
Phantom
3
4
Fig. 4: Connection diagram with MPA III L.
Refer to fig. 4.
2.3.3 Connecting
to a Bodypack
Transmitter
18
Mini XLR Mini XLR
1
4. If your mixer provides no phantom power:
Connect the MPA III L (3) to an optional AKG
phantom power supply (4) (N 62 E, N 66 E, B 18,
B 15) and use an XLR cable (5) (e.g., an optional
MK 9/10 from AKG) to connect the phantom
power supply (4) to the desired balanc ed input.
Refer to the manual of your bodypack transmitter.
MPA
2
3
5
