7. Technical data

DN100
Tanks 2 x 2,700 L
Inhabitants 2-7 PE
Max. daily inflow 1.05
Length L 2080 mm
Width B
1565 mm
Height H
1690 / 2010* mm
tot
Inlet Z1
430 / 750* mm
Inlet Z2 1260 mm
Outlet A1
470 / 800* mm
Outlet A2 1255 mm
* with maxi tank dome
7. Technical data
L
2 x 3,750 L
8-10 PE
3 3
1.50
m /d m /d
2280 mm
1755 mm
1870 / 2200* mm
430 / 750* mm
1450 mm
470 / 800* mm
1445 mm
24 / 36
