• Only use the device for its intended purpose. Using the device in an
unauthorised way will void the warranty.
4. Features
• ultracompact portable speaker, only 16.8mm thick
• super neodymium-iron-boron magnet speaker Driver
• class D amplifier IC
• good sound quality and easy to use
• electronic volume control
• comes with stand, strap, male-male earphone cable, USB cable and
pouch included
5. Overview
Refer to the illustration on page 2 of this manual.
A volume down (-) button
B volume up (+) button
C signal input jack
D mini USB port
6. Operation
• Insert the cable from a music source (not incl.) into the signal input
jack [C] and switch the external music signal on. Use the included
male-male convertor cable when necessary.
• The audio speaker can be powered via the USB port [D] or via
batteries (not incl.). Use the included USB cable to connect the
speaker to a free USB port from a computer (not incl.) or a power
adapter (not incl.).
• Set the power switch [F] towards the status LED [E]) when using
a USB power source; slide it away from the power LED [E] when
using battery power. Note that when the USB port is powered,
the audio speaker will not work when switched to battery setting,
even when batteries are present!
• When the audio speaker is powered, the red status LED [E] is on.
• Adjust the volume with the volume down [A] or volume up [B]
buttons.
• When the sound output is distorted, check the battery status and
the quality of the input signal.
• Switch the speaker off by moving the power switch [F] to the
middle position.
00-13/11/2008
PCSP12
E status LED
F power switch
G battery cover
