ACCESSORIES AND CONSUMABLES
Accessories
Consumables
Regularly check the wear condition of the protective tip, nozzle and electrode or in case of significant reduce of the
cutting speed.
It is advised to replace at the same time the nozzle and the electrode.

TROUBLESHOOTING

Anomalies
At startup, the display shows 'Er1'
At startup, the display shows 'Er2'
At startup, the display shows '- - -'
In operation, the display shows '- - -'
The machine delivers no power and the
indicator (3) is on
The machine delivers no power and the
indicator (4) is on
The display shows 'no Air'
The machine delivers no power and the display
shows 'Er3'
The machine delivers no power and the display
shows 'Er4'
The display shows 'Er5'
Compass divider kit
040205)
For circular cutting up to
134 cm diameter.
Provided with
magnetic, with center pin,
with thread
Replace if cracked or damaged
Tip
Clean if the inside of the nozzle is blocked or
Nozzle dirty.
Replace if the opening is deformed or if the
size of the orifice has half increased.
Diffuser
Replace if lateral orifices are bolcked.
To replace: if a significant cavity appears at
Electrode
the electrode center.
The device was turned on with the
trigger pressed
One or more buttons on the keypad are
pressed
The machine
unsuitable power supply (out of 85-265V
range)
The overvoltage protection is active.
The thermal protection of the Plasma
Cutter is active
The torch nozzle is not in place
The air pressure is too low
No contact between the electrode and
the nozzle
The electrode cannot retract
The cutting cycle has stopped abnormally
(ref.
3 axes:
Causes
is connected to an
Trolley
Ref. 040199)
(
For a comfortable use and be
at the advised height
For optimizing the cutting
performances and increase
the nozzles life-time.
Plasma 40FV
040236
040212
040175
040168
Remedies
Release the trigger
Release the button(s)
Check the electrical system or generator
Wait until the end of the cooling phase
Turn off the machine, check and replace the
consumables, turn on the machine
Check that the air supply is properly
connected to the machine, adjust the air
pressure
Turn off the product,
consummables, check the electrode retracts
and returns easily. Try again.
Turn off the product, make sure that the
electrode can retract and return easily. Try
again
Turn off the product, wait until the error
disappears, try again. If the error persists
return the product for inspection
check the
