Operations

Multifunctional endpiece

Distance unit setting

Switch between the
following units:
2 sec
0.000 m
0.0000 m
0.00 m

Timer (automatic release)

1 2

Tilt unit setting

0.00 ft
2 sec
0'00" 1/32
simultaneously
0.00 in
0 in 1/32
Adjust delay of au-
tomatic release
(max. 60 sec,
standard setting
5 sec)
The orientation
of the endpiece
is automatically
detected and
the zero point is
accordingly ad-
justed.
Switch between the
following units:
180 °
0.0 %
Once the key is released with the la-
ser activated, the remaining seconds
until the measurement are displayed
in a countdown. The delayed release
is recommended for precise aiming
e.g. at long distances. It avoids shak-
ing of the device when pressing the
measurement key.
